    MISSION "L" FOR NATIONAL 12-P-160 (7500 PSI WORKING PRESSURE)， NATIONAL 12P160 MUD PUMP FLUID END LINER, VAVLE, PISTON

    Ask Lasest Price
    Brand Name : OILWELL, GARDNER DENVERNATIONAL, EMSCO, DRILLMEC, GARDNER DENVER
    Model Number : A1700PT
    Certification : API
    Payment Terms : T/T, L/C, D/A, D/P, T/T, Western Union
    Supply Ability : 3000 per month
    Delivery Time : In stock
    Price : 1 to 500 usd
    • Product Details
    • Company Profile

    MISSION "L" FOR NATIONAL 12-P-160 (7500 PSI WORKING PRESSURE)， NATIONAL 12P160 MUD PUMP FLUID END LINER, VAVLE, PISTON

    www.premiumrigparts.com

    MISSION "L" FOR NATIONAL 12-P-160 (7500 PSI WORKING PRESSURE)， NATIONAL 12P160 MUD PUMP FLUID END LINER, VAVLE, PISTON


    MISSION "L" FOR NATIONAL 12-P-160 (7500 PSI WORKING PRESSURE)QTY PER PUMP
    FLUID END MODULE & ACCESSORIES (INCLUDING DISCHARGE MANIFOLD)
    ITEM #MISSION PART #DESCRIPTION
    80704032FLUID END ASSEMBLY COMPLETE INCLUDES ITEMS (1-27) ENOUGH FOR 1 PUMP1
    180704000MODULE, DISCHARGE STUDDED (INCLUDES ITEMS 1,9,10,13,14,18,19,20,& 27)3
    280704001MODULE, SUCTION STUDDED (INCLUDES ITEMS 2,3,4,18,&19)3
    380704002STUD, (DISCHARGE TO SUCTION MODULE)24
    4PEP55NUT, HEAVY HEX24
    580704003THREADED RING6
    680704004THREADED CAP6
    780704005VALVE COVER (INCLUDES 11,12,& 17)6
    880704006DISCHARGE MANIFOLD (7500 PSI WORKING PRESSURE)1
    980702011STUD, DISCHARGE MANIFOLD12
    10IDT800TRSNNUT,HEX HEAVY12
    11PZ789VGIBUSHING, VALVE GUIDE6
    1212PVGASWGUIDE, VALVE6
    138P80TRSNNUT, POWER FRAME STUD30
    14PEP75CAPSCREW, LINER RETAINER18
    1512PLASWRETAINER, LINER FLANGE3
    1612PLANSWNUT, LINER RETAINER3
    177007303SCREW, VALVE GUIDE12
    186300240NUT, HEAVY HEX FOR THREADED RING72
    1980700014STUD, THREADED RING72
    20PEP70PIN, DOWELL6
    211290344SEAL, DISCH TO SUC & WEARPLATE - RUBBER (SEE DATASHEET FOR ALT MATLS)6
    2207207129SEAL, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS)3
    2399609235SEAL, DISCHARGE MANIFOLD3
    241540851SEAL, SUCTION MANIFOLD3
    25700048511CAPSCREW, SUCTION MANIFOLD3
    26PP6021260SWWEARPLATE3
    27NAT12P160PFSSTUD, POWER FRAME30

    MISSION "L" FOR NATIONAL 12-P-160 (7500 PSI WORKING PRESSURE)， NATIONAL 12P160 MUD PUMP FLUID END LINER, VAVLE, PISTON


    High Chrome Sleeve Liner


    The outer hull, or body, of the liner is a high strength forging. Premium uses forgings exclusively to ensure the consistent quality. The sleeve is centrifugally cast in the Premium facilities by skilled craftsmen. It has the maximum amount of chrome for the base metal and Premium adds molybdenum to increase the hardness depth. The sleeve is then inserted into the hull at a tightness that exceeds its counterparts. The liner is rated to match the pressure rating of the pump per liner size.


    Rated for all drilling operations up to 5,000 PSI and above

    Bore hardness is 62 - 69 Rockwell

    Plip design to prevent inner sleeve slippage

    Extremely long service life


    Mud Pump Models


    Liner Inch

    		4”4-1/2”5”5-1/2”6”6-1/2”7”
    Continental Emsco F-800 / 1000/054954500549550005495550054956000549565005495700
    Continental Emsco FB-1300 / 160005499400054994500549950005499550054996000549965005499700
    Continental Emsco FC-2200//0555150005551550055516000555165005551700
    Gardner Denver PAH-275

    PA I3940

    05519400

    PA 13945

    05445450

    PA 13950

    05445500

    		////
    Gardner Denver PZ-7PY13940PY13945

    PY13950

    05493087

    PY13955

    05493085

    PY13960

    05493083

    PY13965

    05493081

    PY13970

    05493079

    Gardner Denver PZ-8/9

    206PZJ456

    05493400

    205PZJ456

    05493450

    204PZJ456

    05493500

    203PZJ456

    05493550

    202PZJ456

    05493600

    200PZJ456

    05493650

    207PZJ456

    05493700

    Gardner Denver PZ-10/11

    206PZL456

    05496400

    205PZL456

    05496450

    204PZL456

    05496500

    203PZL456

    05496550

    202PZL456

    05496600

    201PZL456

    05496650

    200PZL456

    05496700

    Gardner Denver PZL

    206PZL456

    05496400

    205PZL456

    05496450

    204PZL456

    05496500

    203PZL456

    05496550

    202PZL456

    05496600

    201PZL456

    05496650

    200PZL456

    05496700

    Gardner Denver PZL-B-7500 PSI//05561500HP05561550HP05561600HP05561650HP05561700HP
    Gardner Denver PZL W/SWFE 7500 PSI05465400HP05465450HP05465500HP05465550HP05465600HP05465650HP05465700HP
    Gardner Denver PX-11 7500 PSI//05561500HP05561550HP05561600HP05561650HP05561700HP
    Ideco T-500/055124500551250005512550055126000551265005512700
    Ideco T-800 / 100005502400055024500550250005502550055026000550265005502700
    Ideco T-1300 / 1600/055074500550750005507550055076000550765005507700
    National 7P-500546604005466045054660500546605505466060//
    National 8-P-80054644000546445005464500054645500546460005464650/
    National 9-P-100 / 10-P-130054654000546545005465500054655500546560005465650/
    National 12-P-16005466400054664500546650005466550054666000546665005466700
    National 14-P-22005545400055454500554550005545550055456000554565005545700
    National JWS-165/3400553140005531450/////
    National JWS-4000552440005524450055245000552455005524600//
    Oilwell HD-1700-PT//0532650005326550053266000532665005326700
    Oilwell A-600-PT05329400053294500532950005329550053296000532965005329700
    Oilwell A-850-PT / A-1100-PT05330400053304500533050005330550053306000533065005330700
    Oilwell A-1400-PT / A-1700-PT05326400053264500532650005326550053266000532665005326700

    MISSION "L" FOR NATIONAL 12-P-160 (7500 PSI WORKING PRESSURE)， NATIONAL 12P160 MUD PUMP FLUID END LINER, VAVLE, PISTON


    MISSION "L" NEW STYLE MODULE FOR NATIONAL 12-P-160QTY PER PUMP
    FLUID END MODULE & ACCESSORIES
    ITEM #OEM PART #MISSION PART #
    FEM12PASSYSWNSFLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEMS: 1-23)3
    18476-6SFEM12PSUCSWNSMODULE, SUCTION STUDDED (INCLUDES ITEMS: 1,13,14,& 22)3
    28476-5DFEM12PDISSWNSMODULE, DISCHARGE STUDDED - (INCLUDES ITEMS: 2,3,4,5,6,7,8,13 & 14)3
    34018-1712P160DSUCSSTUD, DISCHARGE TO SUCTION MODULE18
    4PEP55NUT, DISCHARGE TO SUCTION STUD18
    54015-95NAT12P160PFSSTUD, POWER END30
    68P80TRSNNUT, POWER END STUD30
    78488-5PEP70PIN, DOWELL6
    84017-65PEP75CAPSCREW,LINER RETAINER SOCKET HEAD18
    98476-3PP6021260SWPLATE, LINER WEAR3
    1029881290344GASKET, WEAR PLATE AND MODULE - RUBBER (SEE DATASHEET FOR ALT MATLS)6
    11647612PLASWFLANGE, LINER RETAINER (LINER BUSHING)3
    12657612PLANSWNUT, LINER RETAINER3
    134015-5412PTRSSWSTUD, THREADED RING72
    1412P160TRSNNUT, THREADED RING STUD72
    154676-6A12PVCASSYSWNSPLUG, VALVE COVER (INCLUDES ITEMS 15,19,20,& 21)6
    16447612PFLGSWRING, THREADED (THREADED FLANGE)6
    17459712PCAPSWCAP, THREADED (SCREW GLAND)6
    18P-11907207119SEAL, VALVE COVER PLUG - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS)6
    194776R12PVGASWNSASSEMBLY, VALVE GUIDE(INCLUDES ITEMS 19,& 20)6
    204700-IPZ789VGIBUSHING, VALVE GUIDE6
    214016-98PEP73SCREW, VALVE GUIDE12
    224018-19700048511CAPSCREW, SUCTION MANIFOLD24
    23AJO-419R1540851GASKET, SUCTION MANIFOLD3
    248376-2NAT12PDSMAADAPTER, DISCHARGE2
    252976-22410031437SEAL, DISCHARGE ADAPTER4
    268376-1NAT12PDSMCCONNECTOR, DISCHARGE2
    272976-12410031433SEAL, DISCHARGE CONNECTOR TO DISCHARGE ADAPTER2
    284018-18700030711CAPSCREW, DISCHARGE CONNECTOR (W /LOCKWASHER)16
    298376-31292175RING, BACKUP (DISCHARGE CONNECTOR)4
    304018-397006685CAPSCREW, SOCKET HEAD 1 1/2" X 3"16
    07924542KIT, MODULE SEAL: (KIT INCLUDES SUCTION MANIFOLD GASKET, TWO VALVE COVER GASKETS, SUCTION TO DISCHARGE MODULE GASKET, TWO DISCHARGE ADAPTING GASKETS, TWO DISCHARGE CONNECTING GASKETS, WEAR PLATE GASKET)3

    MISSION "L" FOR NATIONAL 12-P-160 (7500 PSI WORKING PRESSURE)， NATIONAL 12P160 MUD PUMP FLUID END LINER, VAVLE, PISTON

    All our fluid end parts are manufactured to API 7K quality standards.

    Parts are available for these popular pump models:

    BOMCO/Emsco Mud Pumps:F2200HL, F1600HL, F-1300, F-1600, FB1300, FB1600, F-800, F-1000, F-500, F-350, DB-550, DA-700, FA-1600/1300, FC-2200, D-300/500, D-375, D-700,

    LS National Mud Pumps: 3NB-500C, 3NB1000C, 3NB1300C, 3NB1600


    Ideco Mud Pumps: T-500, T-800, T-1000, T-1300, T-1600,


    National Mud Pumps: 7P50, 8P80, 9P100, 10P130, 12P160, N1300, C-250, K-700, 14-P-220, E-700/G-1000, K-500, K-380, K-500A/700A, C-250/350, JWS-400,


    Gardner Denver Mud Pumps: PZ7, PZ8/9, PZ10/11, FK-FXK, FY-FXD, FD-FXX, FG-GXG, FG-FXG, KG-KXG, FQ-FXQ, FF-FXF, FF-FXP,

    Oilwell Mud Pumps: A-560/600-PT, A-850-PT/A-1100-PT, A-1700-PT/A-1400-PT


    Wirth Mud Pump: TPK1000, TPK1600, TPK 2000,TPK2200


    Russian Mud Pumps: UNBT-950, UNB-600, 8T-650, UNBT650, NBT600, UNB1180, UNB1180L, NB125, NB80, NB50, NB32


    WEATHERFORD/Ellis Williams: E-447, E-2200


    Drillmec Mud Pump: 9T1000, 12T1600, 7TS600, 7TS500, 9T800


    Romania Mud Pump: 3PN-1000, 3PN-1600, 3PN-2000


    And other brand spare parts for WIRTH, OPI, Ellis Williams, Wilson, Gaso, Skytop/Brewster.


    MISSION "L" FOR NATIONAL 12-P-160 (7500 PSI WORKING PRESSURE)， NATIONAL 12P160 MUD PUMP FLUID END LINER, VAVLE, PISTON


    1,Plunger Size 3.38” - 4.00” Valve Part No. P107185 Seat Part No. P107802
    Insert Part No. P107186 Spring
    2,Plunger Size 4.50” Valve Part No. P107181 Seat Part No. P107180
    Insert Part No. P107182 Spring
    3,Plunger Size 5.00” - 6.00” Valve Part No. P107188 Seat Part No. P107187
    Insert Part No. P107189 Spring4P102382
    SPM2000
    1,Plunger Size 3.75" Plunge Part No 3P103887
    2,Plunger Size 4.00" Plunge Part No 3P100339
    3,Plunger Size 4.50" Plunge Part No 3P100654
    4,Plunger Size" 5.00" Plunge Part No 3P100233
    5,Plunger Size" 5.50 Plunge Part No 3P107060
    6,Plunger Size" 5.75" Plunge Part No 3P107061
    7,Plunger Size 6.00 Plunge Part No 3P107062
    SPM
    TWS 250 Plunger Size 1.75"-3" 3.25"-4"
    TWS 400 Plunger Size 2 .50"-3" 3 .50"-4 .50”
    TWS 500LW-600 Plunger Size 2 .75" 3"-4 .75"
    TWS 600S Plunger Size 2 .50"-3" 3.50"-4 .50"
    TWS 900 Plunger Size 3.50"-4"
    TWS 1250LW Plunger Size 4"
    OPI880 Plunger Size 3.75" 4.00” 4.5” 5.0:” 5.50” 5.75” 6.0”
    TWS1000LW,TWS1300
    Plunger Size 3.75" 4.00” 4.5” 5.0:” 5.50” 5.75” 6.0” 6.5 “ 6.75”
    TWS1600 Plunger Size 3.5” 3.75” 4.0” 4.50” 5.0” 5.5” 5.75 “6.0”
    TWS1800 Plunger Size 3.5” 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0”
    TWS2250 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
    QWS 2000 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
    QWS 2500 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
    5.50” 5.75” 6.0”
    TWS2250 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
    QWS 2000 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
    QWS 2500 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5


    MISSION "L" FOR NATIONAL 12-P-160 (7500 PSI WORKING PRESSURE)， NATIONAL 12P160 MUD PUMP FLUID END LINER, VAVLE, PISTON


    Brewster ® Mud Pumps B-550 • B-750 • B-1000 • 1100T • B-1300
    Continental Emsco ® Mud Pumps F-350 • F-500 • F-650 • F-800 • F-1000 • FA-1300 • FB-1600 FB1600
    Gaso ® Mud Pump 1563 • 1740-55 • 1844-60 • 2010-50 • 2200-49 • 2651 • 2652
    Gardner Denver ® Mud Pumps
    PAH • PZ-7 PZG • PZ-8 PZH • PZ-9 PZJ • PZ-10 PZK • PZ-11 PZL
    Gardner Denver ® Well Service TEE • PE-5 • PA-8 • PAH • PJ-8 • TGF-225
    Gardner Denver ® Continuous Duty GD-55T • GD-60T • GD-100T • GD-125T • GD-150T • GD-180T • GD-200T
    Ideco ® Mud Pumps MM-200 • MM-300 • MM-500 • MM-500F • MM-550
    Ideco ® Mud Pumps MM-550F • MM-700 • MM-700F • T-500
    Ideco ® Mud Pumps T-500 • T-800 • T-1000 • T-1300 • T-1600
    National ® J Series Mud Pumps J-30 • J-60 • J-100 • J-165 • J-275 • J-375 • J-625 • JWS-340 • JWS-400
    National ® Mud Pumps K-280 • K-380 • K-500 • K-500A • K-700A
    National ® P Series Mud Pumps 7P-50 • 8P-80 • 9P-100 • 10P-130 • 12-P-160 / 12P-160 / 12P160
    Oilwell ® Mud Pumps A-350-PT • 560-PT • A-560-PT • 850-PT • A-850-PT • 1100-PT
    Oilwell ® Mud Pumps A-1100-PT • 1400-PT • A-1400-PT • 1700-PT • A-1700-PT / A1700-PT
    Oilwell ® Plunger Pumps C-323 through B-558 • SA-640-50 through SB-644-B
    OPI ® Mud Pumps 350-D • 00-DL • 700-HDL • 1000-HDL
    Wheatley ® Mud Pumps 1036 • 6070 • 7024 • 7036
    Fluid End Modules
    National® - Oilwell® - Continental Emsco® - Gardner Denver® - Ideco® - Skytop Brewster®
    Pulsation Dampener
    Hydril Type "K" Pulsation Dampener
    Popular Mud Pump Spare Parts


    MISSION "L" FOR NATIONAL 12-P-160 (7500 PSI WORKING PRESSURE)， NATIONAL 12P160 MUD PUMP FLUID END LINER, VAVLE, PISTON


    Brewster ® Mud Pumps B-550 • B-750 • B-1000 • 1100T • B-1300

    Continental Emsco ® Mud Pumps F-350 • F-500 • F-650 • F-800 • F-1000 • FA-1300 • FB-1600 FB1600

    Gaso ® Mud Pump 1563 • 1740-55 • 1844-60 • 2010-50 • 2200-49 • 2651 • 2652

    Gardner Denver ® Mud Pumps

    PAH • PZ-7 PZG • PZ-8 PZH • PZ-9 PZJ • PZ-10 PZK • PZ-11 PZL

    Gardner Denver ® Well Service TEE • PE-5 • PA-8 • PAH • PJ-8 • TGF-225

    Gardner Denver ® Continuous Duty GD-55T • GD-60T • GD-100T • GD-125T • GD-150T • GD-180T • GD-200T

    Ideco ® Mud Pumps MM-200 • MM-300 • MM-500 • MM-500F • MM-550

    Ideco ® Mud Pumps MM-550F • MM-700 • MM-700F • T-500

    Ideco ® Mud Pumps T-500 • T-800 • T-1000 • T-1300 • T-1600

    National ® J Series Mud Pumps J-30 • J-60 • J-100 • J-165 • J-275 • J-375 • J-625 • JWS-340 • JWS-400

    National ® Mud Pumps K-280 • K-380 • K-500 • K-500A • K-700A

    National ® P Series Mud Pumps 7P-50 • 8P-80 • 9P-100 • 10P-130 • 12-P-160 / 12P-160 / 12P160

    Oilwell ® Mud Pumps A-350-PT • 560-PT • A-560-PT • 850-PT • A-850-PT • 1100-PT

    Oilwell ® Mud Pumps A-1100-PT • 1400-PT • A-1400-PT • 1700-PT • A-1700-PT / A1700-PT

    Oilwell ® Plunger Pumps C-323 through B-558 • SA-640-50 through SB-644-B

    OPI ® Mud Pumps 350-D • 00-DL • 700-HDL • 1000-HDL

    Wheatley ® Mud Pumps 1036 • 6070 • 7024 • 7036

    Fluid End Modules

    National® - Oilwell® - Continental Emsco® - Gardner Denver® - Ideco® - Skytop Brewster®

    Pulsation Dampener

    Hydril Type "K" Pulsation Dampener

    Popular Mud Pump Spare Parts


    Mud Pump Manufactures and Models include:

    Brewster Mud Pumps

    B-550 | B-750 | B-1000 | 1100T | B-1300

    Continental Emsco Mud Pumps

    FF-FXF | FG-FXG (A thrugh L) | FD-FXX | FC-FXX | FD-FXD | FC-FXD | FY-FXD

    Continental Emsco Mud Pumps

    GP-GXP | GR-GXP | GP-GXR | GR-GXR |PA-8 | PAH

    Continental Emsco Mud Pumps

    PJ8 | PZ-7 | PZ-8 | PZ-9 | PZ-10 | PZ-11 | PXL

    Ellis Williams (Luko) Mud Pumps

    WW-440 | 14W-400 | 15W-600 | 9W-1000

    Gaso Mud Pump

    1563 | 1740-55 | 1844-60 | 2010-50 | 2200-49 | 2651 | 2652

    Gardner Denver Mud Pumps

    FF-FXF;FG-FXG;A thru L FD-FXX FC-FXX FD-FXD FC-FXD FY-FXD GP-GXP GR-GXP GP-GXR GR-GXR PA-8 PJ8 PZ-7 PZ-8 PZ-9 PZ-10 PZ-11 PXL


    Ideco Mud Pumps

    MM-200 | MM-300 | MM-500 | MM-500F | MM-550

    Ideco Mud Pumps

    MM-550F | MM-700 | MM-700F | T-500

    Ideco Mud Pumps

    T-800 | T-1000 | T-1300 | T-1600

    National Mud Pumps

    C-150 | C-250 | C-350 | E-500 | E-700 | G-700 | G-1000


    National Mud Pumps

    K-280 | K-380 | K-500 | K-500A | K-700A


    National Mud Pumps

    7P-50 | 8P-80 | 9P-100 | 10P-130 | 12P-160


    Oilwell Mud Pumps

    6P-HD | 610-P | 212-P | 214-P | 218-P


    Oilwell Mud Pumps

    350-PT | 560-PT | A-560-PT | 850-PT | A-850-PT | 1100-PT


    Oilwell Mud Pumps

    A-1100-PT | 1400-PT | A-1400-PT | 1700-PT | A-1700-PT


    OPI Mud Pumps

    350-D | 700-HDL | 1000-HDL


    Wheatley Mud Pumps

    1036 | 6070 | 7024 | 7036


    Wilson Mud Pumps

    600 | 900



    MISSION "L" FOR NATIONAL 12-P-160 (7500 PSI WORKING PRESSURE)， NATIONAL 12P160 MUD PUMP FLUID END LINER, VAVLE, PISTON


    MISSION "L" MODULE FOR PZ-8QTY PER PUMP
    FLUID END MODULE & ACCESSORIES
    ITEM #OEM PART #MISSION PART #
    FEMPZ9ASSYSWMODULE, COMPLETE ASSEMBLY FLUID END (INCLUDES ITEMS 1-26)1
    18475-1DFEMPZ9DISSWMODULE, STUDDED DISCHARGE (INCLUDES ITEMS 1, 3-11)1
    28475-2SFEMPZ9SUCSWMODULE, STUDDED SUCTION - (INCLUDES ITEMS 2, 5, 6, 12 & 24)1
    34016-97OWA17DSUCSSWSTUD, DISCHARGE TO SUCTION MODULE6
    4EMSF1000PFSNNUT, DISCHARGE TO SUCTION STUD6
    54015-2OWA17TRSSWSTUD, THREADED RING24
    6PZ789LCSNNUT, THREADED RING STUD40
    74017-56PZ9GPFSSWSTUD, POWER FRAME (SHORT)4
    875510412NUT, POWER FRAME STUD4
    94016-14PZ9LCSSWSTUD, LINER RETAINER (LONG)8
    104017-5PZ1011DMSSWSTUD, DISCHARGE MANIFOLD4
    11PZ789TRSNNUT, DISCHARGE MANIFOLD STUD8
    128488-5PEP70DOWELL PIN2
    1329881290344SEAL, SUCTION TO DISCHARGE MODULE1
    142930-0807932009SEAL, WEAR PLATE - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS)1
    158477-3PZ1011WPSWWEAR PLATE1
    168475-3PZ9LCLINER RETAINER1
    17P-12907207129VALVE COVER SEAL - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS)2
    184016-99PEP73VALVE GUIDE SCREW4
    194775ROWA17VGASWVALVE GUIDE (INCLUDES ITEMS 19, 23)2
    204675-1AOWA17VCSWVALVE COVER PLUG (INCLUDES ITEM 18-20 & 23)2
    214475OWA17FLGSWTHREADED FLANGE2
    224575OWA17CAPSWTHREADED CAP2
    234700-IPZ789VGIVALVE GUIDE BUSHING2
    244017-77700044111MANIFOLD CAPSCREW, SUCTION8
    25AJO-449R114252430GASKET, DISCHARGE MANIFOLD3
    268014G52007923283GASKET, SUCTION MANIFOLD3

    MISSION "L" FOR NATIONAL 12-P-160 (7500 PSI WORKING PRESSURE)， NATIONAL 12P160 MUD PUMP FLUID END LINER, VAVLE, PISTON


    CONTINENTAL EMSCO FC-2200QTY PER PUMP
    ITEM #OEM PART #
    EMSFEMFC2200CAFLUID END MODULE COMPLETE ASSEMBLY
    10-6323-0108-00EMSFEMFC2200DISDISCHARGE MODULE-STUDDED
    20-6323-0109-00EMSFEMFC2200SUCSUCTION MODULE-STUDDED
    30-6323-0087-00THREADED RETAINER
    40-6323-0086-00THREADED RING
    50-6323-0083-00VALVE POT COVER
    60-6323-0103-00VALVE GUIDE W/ BUSHING
    70-6323-0126-00HANDLER, VALVE POT
    80-6323-0085-00SUCTION MANIFOLD
    90-6316-0105-95FLANGE, SUCTION
    100-6317-0074-95FLANGE, BLIND
    110-6323-0084-10DISCHARGE MANIFOLD, 7500 PSI
    120-6323-0097-00WEAR PLATE
    13
    140-6323-0096-00LINER THREAD RING
    150-6323-0099-00LINER LOCK
    16
    170-6323-0121-20FEED PIPING ASSEMBLY
    180-6323-0093-00RETAINER, VALVE GUIDE
    190-6323-0128-00SEAL, F. E. MODULAR
    200-6323-0127-00WEAR PLATE LINER SEAL - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS)
    21
    220-7602-1600-52O-RING (SUCTION MANIFOLD)
    230-7602-1600-61O-RING (SUCTION MANIFOLD TO F. E.)
    240-7602-1600-30O-RING (DISCHARGE MANIFOLD TO F. E.)
    250-7501-0051-00SCREW, RETAINER
    260-7602-5280-72WIRE, SOFT IRON .06 X 144.00
    27
    280-7601-0331-39SCREW, HEX HD 1" - 8 X 5.00
    290-7601-0630-20NUT, HEX 1" - 8
    30
    310-7601-0333-30SCREW, HEX HD 7/8-9 X 2.50 GR 5

    Quality MISSION "L" FOR NATIONAL 12-P-160 (7500 PSI WORKING PRESSURE)， NATIONAL 12P160 MUD PUMP FLUID END LINER, VAVLE, PISTON for sale

    MISSION "L" FOR NATIONAL 12-P-160 (7500 PSI WORKING PRESSURE)， NATIONAL 12P160 MUD PUMP FLUID END LINER, VAVLE, PISTON

    Inquiry Cart 0
    Send your message to this supplier

    *From:
    *To: Qingdao National Premium Oilwell Machinery Co.,Ltd
    *Subject:
    *Message:
    Characters Remaining: (0/3000)

    Find Similar Products By Category:
    Textiles & Leather Products
    Hot Searches:

    Friendly Links: www.everychina.com

    Home| Products| Suppliers| Site Map |About Us |Contact Us |Help |关于我们 |联系我们

    Copyright © 2009 - 2025 himfr.com. All rights reserved.

    北京环球广贸软件技术有限责任公司
