TSC Fluid end module of mud pumps:
| Mud Pump Models | Module with Stud | Mud Pump Models | Module with Stud |
| Continental Emsco F-800 / 1000 | 6999-0086-02 | National 12-P-160 Discharge | 1292240 |
| Continental Emsco FB-1300 / 1600 | 6316-0357-00 | National 12-P-160 Suction | 1292243 |
| Gardner Denver TEE | 200PJH029B | National 14-P-220 Discharge | 1295601 |
| Gardner Denver PAH | 200PJH029B | National 14-P-220 Suction | 1295604 |
| Gardner Denver PZ-7/8/9 | 205PZL029D | Module, WF400 | TSC-SP-WF400-01 |
| Gardner Denver PZ-10/11 | 202PZL029B | Module, WF700 | TSC-SP-WF700-01 |
| Ideco T-800 / 1000 | 551-458 | Module, WF1300B | TSC-SP-WF1300-01 |
| Ideco T-1000 / 1300 | 551-122-01 | Module, WF1300C | TSC-SP-WF1300-02 |
| Oilwell A-850-PT / A-1100-PT | 10300181 | Module, WF1300BH | TSC-SP-WF1300-03 |
| Oilwell A-1400-PT / A-1700-PT | 10300181 | Module, WF1600A | TSC-SP-WF700-01 |
| National 8-P-80 Discarge | 1291280 | Module, WF1600B | TSC-SP-WF1600-01 |
| National 8-P-80 Suction | 1290338 | Module, WF1600BH | TSC-SP-WF1600-02 |
| National 9-P-100 Discharge | 1293240 | Module, WF1600L | TSC-SP-WF1600-03 |
| National 9-P-100 Suction | 1290338 | Module, WF1600LH | TSC-SP-WF1600-05 |
| National 10-P-130 Discharge | 1290335 | Module, WF1600S | TSC-SP-WF1600-06 |
| National 10-P-130 Suction | 1290338 | Module, WF2000 | TSC-SP-WF2000-01 |
| | | Module, WF2200 | TSC-SP-WF2200-01 |
TSC mud pump liners are designed and manufactured to meet or exceed original equipment specification and API standards for almost all types of mud pumps in use today.
TSC Workforce (WF) series mud pumps are developed to offer superior performance for a variety of drilling operations and work environments. TSC Mud pump and parts for model:
WF1300 triplex Pump,WF1300BH,WF1300,WF-1300C,WF1600A,WF1600B,WF1600BH,WF1600CH,WF1600L,WF1600LH,WF2000,WF2200.WF400,WF700.
www.t-s-c.com
| | | |
| | | |
| TSC PART # | DESCRIPTION | WEIGHT |
| TS-1293240 | MODULE, STUDDED FLUID END DISCHARGE ( INCLUDES ITEMS 1,3-6, 9-11, 30&31) | 1365 |
| TS-1290338 | MODULE, STUDDED FLUID END SUCTION (INCLUDES ITEMS 2,3,4 ) | 680 |
| TS-2408019 | STUD, THREADED RING | 3.12 |
| TS-6300220 | NUT, THREADED RING STUD | 0.74 |
| TS-2408030 | STUD, POWER FRAME | 1.75 |
| TS-6300200 | NUT, POWER FRAME STUD | 0.5 |
| TS-2402560 | STUD,TOP TAPER LOCK (FOR BLIND RING AND WELD NECK FLANGES) | 1.75 |
| TS-6300200 | NUT, STUD (BLIND RING AND WELD NECK FLANGES) | 0.5 |
| TS-2408034 | STUD, DISCHARGE MODULE TO SUCTION MODULE | 9.5 |
| TS-6300241 | NUT, DISCHARGE TO SUCTION MODULE STUD | 0.94 |
| TS-6511416 | PIN, DOWELL | 0.5 |
| TS-1292141 | BUSHING,VALVE GUIDE | 1 |
| TS-1292140 | RETAINER, VALVE GUIDE BUSHING | 1 |
| TS-1540126 | GASKET, VALVE COVER | 0.2 |
| TS-1290174 | RETAINER, SEAL | 38 |
| TS-1290178 | SCREW, ADJUSTING WEDGE | 3 |
| TS-G-1290376 | ASSEMBLY, WEDGE (INCLUDES ITEM #18 WEDGE SPRING) | 7 |
| TS-1290181 | SPRING, WEDGE | 1 |
| TS-1290308 | RING, THREADED | 77 |
| TS-1290307 | CAP, VALVE COVER (THREADED) | 70 |
| TS-1290315 | WASHER, WEDGE ADJUSTING SCREW | 0.15 |
| TS-6300160 | NUT, WEDGE ADJUSTING SCREW | 0.5 |
| TS-2410031427 | SEAL,DISCHARGE CONNECTOR & DISCHARGE ADAPTER | 0.05 |
| TS-1290343 | ADAPTER, DISCHARGE CONNECTOR | 5 |
| TS-2410031348 | SEAL,DISCHARGE CONNECTOR TO DISCHARGE ADAPTER | 0.05 |
| TS-1290342 | CONNECTOR, DISCHARGE | 16.75 |
| TS-700030511 | CAPSCREW, DISCHARGE CONNECTOR (WASHER INCLUDED) | 0.05 |
| TS-1290357 | PLATE, WEAR | 10 |
| TS-1293165 | BUSHING, LINER(SAME AS 8P-80 & 10P-130) | 110 |
| TS-2408018 | STUD, LINER BUSHING | 1.2 |
| TS-6300160 | NUT, LINER BUSHING STUD | 0.5 |
| TS-1293166 | ASSEMBLY, LINER CLAMP (INCLUDES ITEMS 32,33,34,35,36,37) | 150 |
| TS-7000448-11 | CAPSCREW, LINER CLAMP | 0.05 |
| TS-6309120 | NUT, LINER CAPSCREW | 0.12 |
| TS-1290169 | PIN, CONNECTOR | 0.15 |
| TS-1290168 | CONNECTOR, LINER CLAMP | 0.2 |
| TS-6571420 | PIN, SPRING | 1 |
| TS-1290344 | SEAL, MODULE & WEARPLATE | 0.2 |
| TS-1590051 | SEAL, SUCTION MANIFOLD | 0.2 |
| NATIONAL 10-P-130 | | | |
| FLUID END MODULE & ACCESSORIES | | | |
| ITEM # | TSC PART # | DESCRIPTION | WEIGHT |
| 01 | TS-1290335 | MODULE, STUDDED FLUID END DISCHARGE ( INCLUDES ITEMS 1,3-6, 9-11, 30,&31) | 1430 |
| 02 | TS-1290338 | MODULE, STUDDED FLUID END SUCTION (INCLUDES ITEMS 2,3,4 ) | 680 |
| 03 | TS-2408019 | STUD, THREADED RING | 3.12 |
| 04 | TS-6300220 | NUT, THREADED RING STUD | 0.73 |
| 05 | TS-2408020 | STUD, POWER FRAME | 1.5 |
| 06 | TS-6300240 | NUT, POWER FRAME STUD | 0.5 |
| 07 | TS-2402560 | STUD,TOP TAPER LOCK (FOR BLIND RING AND WELD NECK FLANGES) | 1.75 |
| 08 | TS-6300220 | NUT, STUD (BLIND RING AND WELD NECK FLANGES) | 0.73 |
| 09 | TS-2408034 | STUD, DISCHARGE MODULE TO SUCTION MODULE | 9.5 |
| 10 | TS-6300241 | NUT, DISCHARGE TO SUCTION MODULE STUD | 0.94 |
| 11 | TS-6511416 | PIN, DOWELL | 0.5 |
| 12 | TS-1292141 | BUSHING,VALVE GUIDE | 1 |
| 13 | TS-1292140 | RETAINER, VALVE GUIDE BUSHING | 1 |
| 14 | TS-1540126 | GASKET, VALVE COVER | 0.2 |
| 15 | TS-1290174 | RETAINER, SEAL | 38 |
| 16 | TS-1290178 | SCREW, ADJUSTING WEDGE | 3 |
| 17 | TS-G1290376 | ASSEMBLY, WEDGE (INCLUDES ITEM #18 WEDGE SPRING) | 7 |
| 18 | TS-1290181 | SPRING, WEDGE | 1 |
| 19 | TS-1290308 | RING, THREADED | 77 |
| 20 | TS-1290307 | CAP, VALVE COVER (THREADED) | 57 |
| 21 | TS-1290315 | WASHER, WEDGE ADJUSTING SCREW | 0.5 |
| 22 | TS-6300160 | NUT, WEDGE ADJUSTING SCREW | 0.5 |
| 23 | TS-1290343 | ADAPTER, DISCHARGE CONNECTOR | 5 |
| 24 | TS-2410031427 | SEAL,DISCHARGE CONNECTOR TO DISCHARGE ADAPTER | 0.5 |
| 25 | TS-1290342 | CONNECTOR, DISCHARGE | 16.75 |
| 26 | TS-2410031348 | SEAL,SUCTION CONNECTOR TO DISCHARGE ADAPTER | 0.5 |
| 27 | TS-700030511 | CAPSCREW, DISCHARGE CONNECTOR (WASHER INCLUDED) | 0.5 |
| 28 | TS-1290357 | PLATE, WEAR | 10 |
| 29 | TS-1290165 | BUSHING, LINER | 110 |
| 30 | TS-2408018 | STUD, LINER BUSHING | 1.2 |
| 31 | TS-6300160 | NUT, LINER BUSHING STUD | 0.5 |
| 32 | TS-1290166 | ASSEMBLY, LINER CLAMP (INCLUDES ITEMS 32,33,34,35,36,37) | 150 |
| 33 | TS-700044811 | CAPSCREW, LINER CLAMP | 0.5 |
| 34 | TS-6309120 | NUT, LINER CAPSCREW | 0.12 |
| 35 | TS-1290169 | PIN, CONNECTOR | 0.15 |
| 36 | TS-1290168 | CONNECTOR, LINER CLAMP | 1 |
| 37 | TS-6571420 | PIN, SPRING | 1 |
| 38 | TS-1290344 | SEAL, MODULE & WEARPLATE | 0.5 |
| 39 | TS-1590051 | SEAL, SUCTION MANIFOLD | 0.5 |
| | | |
| | | |
| TSC PART # | DESCRIPTION | WEIGHT |
| TS-205PZL029D | FLUID END MODULE STUDDED (INCLUDES 1-9 ) | |
| TS-79L188 | STUD, FRAME & LINER CLAMP | |
| TS-50B36 | NUT (FOR ABOVE) | |
| TS-79L73 | STUD, FRAME | |
| TS-50AQ30 | NUT (FOR ABOVE) | |
| TS-79AL6 | STUD, VALVE COVER | |
| TS-50B34 | NUT (FOR ABOVE) | |
| TS-202PZL110 | STUD, DISCHARGE MANIFOLD | |
| TS-50B34 | NUT (FOR ABOVE) | |
| TS-2011861 | RING, VALVE COVER GASKET EXPANDER | |
| TS-2011862(G-749) | GASKET, VALVE COVER | |
| TS-2007674 | BUSHING, VALVE GUIDE | |
| TS-2011860 | COVER, VALVE | |
| TS-2011699 | RING, VALVE COVER THREADED | |
| TS-2011857 | CAP, VALVE COVER LOCK | |
| TS-2011701 | PLATE, RETAINER | |
| TS-2011700 | GUIDE, VALVE SUCTION | |
| TS-95W2 | WASHER, LOCK 1/2" 316SS | |
| TS-655EE06S | SCREW 1/2"x1 3/4" 316SS HX HD C/S | |
| TS-25AL35 | GASKET, DISCHARGE MANIFOLD | |
| TS-25G41 | GASKET, SUCTION MANIFOLD | |
| TS-1PV14 | CLAMP, LINER | |
| TS-2011706 | ASSY., LOWER VALVE GUIDE (INCLUDES 12, 16 -19) | |
All our fluid end parts are manufactured to API 7K quality standards.
Parts are available for these popular pump models:
BOMCO/Emsco Mud Pumps:F2200HL, F1600HL, F-1300, F-1600, FB1300, FB1600, F-800, F-1000, F-500, F-350, DB-550, DA-700, FA-1600/1300, FC-2200, D-300/500, D-375, D-700,
LS National Mud Pumps: 3NB-500C, 3NB1000C, 3NB1300C, 3NB1600
Ideco Mud Pumps: T-500, T-800, T-1000, T-1300, T-1600,
National Mud Pumps: 7P50, 8P80, 9P100, 10P130, 12P160, N1300, C-250, K-700, 14-P-220, E-700/G-1000, K-500, K-380, K-500A/700A, C-250/350, JWS-400,
Gardner Denver Mud Pumps: PZ7, PZ8/9, PZ10/11, FK-FXK, FY-FXD, FD-FXX, FG-GXG, FG-FXG, KG-KXG, FQ-FXQ, FF-FXF, FF-FXP,
Oilwell Mud Pumps: A-560/600-PT, A-850-PT/A-1100-PT, A-1700-PT/A-1400-PT
Wirth Mud Pump: TPK1000, TPK1600, TPK 2000,TPK2200
Russian Mud Pumps: UNBT-950, UNB-600, 8T-650, UNBT650, NBT600, UNB1180, UNB1180L, NB125, NB80, NB50, NB32
WEATHERFORD/Ellis Williams: E-447, E-2200
Drillmec Mud Pump: 9T1000, 12T1600, 7TS600, 7TS500, 9T800
Romania Mud Pump: 3PN-1000, 3PN-1600, 3PN-2000
And other brand spare parts for WIRTH, OPI, Ellis Williams, Wilson, Gaso, Skytop/Brewster.
1,Plunger Size 3.38” - 4.00” Valve Part No. P107185 Seat Part No. P107802
Insert Part No. P107186 Spring
2,Plunger Size 4.50” Valve Part No. P107181 Seat Part No. P107180
Insert Part No. P107182 Spring
3,Plunger Size 5.00” - 6.00” Valve Part No. P107188 Seat Part No. P107187
Insert Part No. P107189 Spring4P102382
SPM2000
1,Plunger Size 3.75" Plunge Part No 3P103887
2,Plunger Size 4.00" Plunge Part No 3P100339
3,Plunger Size 4.50" Plunge Part No 3P100654
4,Plunger Size" 5.00" Plunge Part No 3P100233
5,Plunger Size" 5.50 Plunge Part No 3P107060
6,Plunger Size" 5.75" Plunge Part No 3P107061
7,Plunger Size 6.00 Plunge Part No 3P107062
SPM
TWS 250 Plunger Size 1.75"-3" 3.25"-4"
TWS 400 Plunger Size 2 .50"-3" 3 .50"-4 .50”
TWS 500LW-600 Plunger Size 2 .75" 3"-4 .75"
TWS 600S Plunger Size 2 .50"-3" 3.50"-4 .50"
TWS 900 Plunger Size 3.50"-4"
TWS 1250LW Plunger Size 4"
OPI880 Plunger Size 3.75" 4.00” 4.5” 5.0:” 5.50” 5.75” 6.0”
TWS1000LW,TWS1300
Plunger Size 3.75" 4.00” 4.5” 5.0:” 5.50” 5.75” 6.0” 6.5 “ 6.75”
TWS1600 Plunger Size 3.5” 3.75” 4.0” 4.50” 5.0” 5.5” 5.75 “6.0”
TWS1800 Plunger Size 3.5” 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0”
TWS2250 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
QWS 2000 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
QWS 2500 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
5.50” 5.75” 6.0”
TWS2250 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
QWS 2000 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”
QWS 2500 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5
Brewster ® Mud Pumps B-550 • B-750 • B-1000 • 1100T • B-1300
Continental Emsco ® Mud Pumps F-350 • F-500 • F-650 • F-800 • F-1000 • FA-1300 • FB-1600 FB1600
Gaso ® Mud Pump 1563 • 1740-55 • 1844-60 • 2010-50 • 2200-49 • 2651 • 2652
Gardner Denver ® Mud Pumps
PAH • PZ-7 PZG • PZ-8 PZH • PZ-9 PZJ • PZ-10 PZK • PZ-11 PZL
Gardner Denver ® Well Service TEE • PE-5 • PA-8 • PAH • PJ-8 • TGF-225
Gardner Denver ® Continuous Duty GD-55T • GD-60T • GD-100T • GD-125T • GD-150T • GD-180T • GD-200T
Ideco ® Mud Pumps MM-200 • MM-300 • MM-500 • MM-500F • MM-550
Ideco ® Mud Pumps MM-550F • MM-700 • MM-700F • T-500
Ideco ® Mud Pumps T-500 • T-800 • T-1000 • T-1300 • T-1600
National ® J Series Mud Pumps J-30 • J-60 • J-100 • J-165 • J-275 • J-375 • J-625 • JWS-340 • JWS-400
National ® Mud Pumps K-280 • K-380 • K-500 • K-500A • K-700A
National ® P Series Mud Pumps 7P-50 • 8P-80 • 9P-100 • 10P-130 • 12-P-160 / 12P-160 / 12P160
Oilwell ® Mud Pumps A-350-PT • 560-PT • A-560-PT • 850-PT • A-850-PT • 1100-PT
Oilwell ® Mud Pumps A-1100-PT • 1400-PT • A-1400-PT • 1700-PT • A-1700-PT / A1700-PT
Oilwell ® Plunger Pumps C-323 through B-558 • SA-640-50 through SB-644-B
OPI ® Mud Pumps 350-D • 00-DL • 700-HDL • 1000-HDL
Wheatley ® Mud Pumps 1036 • 6070 • 7024 • 7036
Fluid End Modules
National® - Oilwell® - Continental Emsco® - Gardner Denver® - Ideco® - Skytop Brewster®
Pulsation Dampener
Hydril Type "K" Pulsation Dampener
Popular Mud Pump Spare Parts
| Push Rod Subassembly | | | | | | | |
| L-2 Spacer | | | | | | | |
| | Loc | Qty | Part No. | | | | |
| Retainer,Push Rod HT-400TM, Two Piece Nose, L-Spacer | 1 | 3 | 316.21066. | | | | |
| O-Ring, 90 Duro, 1 7/8 × 1 5/8 × 1/8, 568-223 | 2 | 3 | 8.34020. | | | | |
| Tie Rod, Push Rod, L-Spacer, HT-400TM | 3 | 3 | 316.25166. | | | | |
| Push Rod, Two Piece, L-Spacer, HT-400TM | 4 | 3 | 316.21065. | | | | |
| Retainer, Push Rod Seal Housing, L-2 Spacer, HT-400TM | 5 | 3 | 316.10012. | | | | |
| Housing, Push Rod Seal, Floating, L-2 Spacer, HT-400TM | 6 | 3 | 316.10013. | | | | |
| O-Ring, 70 Duro, 5 11/16 × 5 1/2 × 3/32, 568-161 | 7 | 3 | 70.33739. | | | | |
| Seal, Push Rod, L-Spacer, HT-400TM | 8 | 6 | 316.10014. | | | | |
| | | | | | | | |
| Discharge Valve Subassembly | | | | | | | |
| | | | Plunger Size |
| | Loc | Qty | 3-3/8 inch | 4-inch | 4-1/2 inch | 5-inch | 6-inch |
| Retainer, Cover, HT-400TM | 1 | 3 | 316.2102. | 316.2202. | 316.2202. | 316.2502. | 316.2502. |
| Cover, Discharge, Double Guided Valve, HT-400TM | 2 | 6 | 316.2107. | 316.23091. | 316.23091. | 316.24044 | 316.24044 |
| Gasket, Discharge Valve & Cylinder Head Cover, HT-400TM | 3 | 3 | 316.21052. | 316.22052. | 316.22052. | 316.25052 | 316.25052 |
| Ring, Spacer, Discharge Valve & Cylinder Head Cover, HT-400TM | 4 | 6 | 316.21051. | 316.22051. | 316.22051. | 316.25051. | 316.25051. |
| Liner, Two Piece Bushing, Valve Guide, HT-400, Brass | 5 | 6 | 316.22005. | 316.22005. | 316.22005. | 316.22007. | 316.22007. |
| Insert, Two Piece Bushing, Valve Guide, Special, HT-400 | 6 | 6 | 316.22004. | 316.22004. | 316.22004. | 316.22006 | 316.22006 |
| Spring, Valve, HT-400TM, 36lb/in | 7 | 6 | 316.2108. | 316.2108. | 316.2308. | 316.27259 | 316.27259 |
| Valve, HT-400, Frac | 8 | 6 | 316.21007. | 316.21007. | 316.22048. | 316.24027 | 316.24027 |
| Insert, Valve, HT-400TM, Urethane, Acid/Frac Service(Yellow) | 9 | 6 | 316.21048. | 316.21048. | 316.22046. | 316.24026 | 316.24026 |
| Insert, Valve, HT-400TM, Urethane, Standard Service(Brown) | 9 | 6 | 316.21006. | 316.21006. | 316.22049. | 316.24037 | 316.24037 |
| Seat Valve, HT-400TM, Tapered | 10 | 6 | 316.21008. | 316.21008. | 316.210047. | 316.24024 | 316.24024 |
| O-ring, 90 Duro | 11 | 6 | 8.34037. | 8.34037. | 8.34041. | 8.34045 | 8.34045 |
| Retainer, Guide Bushing, HT400 | 12 | 6 | 316.21096 | 316.21096 | 316.23953 | 316.24043 | 316.24043 |
| | | | | | | | |
| Suction Valve Subassembly | | | | | | | |
| | | | Plunger Size |
| | Loc | Qty | 3-3/8 inch | 4-inch | 4-1/2 inch | 5-inch | 6-inch |
| Retainer, Stop and Spring, HT-400TM, Mach. Cast | 1 | 3 | 316.22977. | 316.22977. | 316.23034 | 316.25840. | 316.25840. |
| Boot, Suction and Stop, HT-400TM | 2 | 6 | 316.25233. | 316.25233. | 316.25233 | 316.25233. | 316.25233. |
| Spring, Lock, HT-400 | 3 | 3 | 316.2125. | 316.2125. | 316.22252. | 316.22253. | 316.22253. |
| Liner, Two Piece Bushing, Valve Guide, HT-400TM, Brass | 4 | 6 | 316.22005. | 316.22005. | 316.22005. | 316.22007. | 316.22007. |
| Insert,Two Piece Bushing, Valve Guide, Special,HT-400TM | 5 | 6 | 316.22004. | 316.22004. | 316.22004. | 316.22006. | 316.22006. |
| Spring, Valve, HT-400TM, 36lb/in | 7 | 6 | 316.2108. | 316.2108. | 316.2308. | 316.27259 | 316.27259 |
| Valve, HT-400, Frac | 8 | 6 | 316.21007. | 316.21007. | 316.22048. | 316.24027 | 316.24027 |
| Insert, Valve, HT-400TM, Urethane, Acid/Frac Service(Yellow) | 9 | 6 | 316.21048. | 316.21048. | 316.22046. | 316.24026 | 316.24026 |
| Insert, Valve, HT-400TM, Urethane, Standard Service(Brown) | 9 | 6 | 316.21006. | 316.21006. | 316.22049. | 316.24037 | 316.24037 |
| Seat Valve, HT-400TM, Tapered | 10 | 6 | 316.21008. | 316.21008. | 316.210047. | 316.24024 | 316.24024 |
| O-ring, 90 Duro | 11 | 6 | 8.34037. | 8.34037. | 8.34041. | 8.34045 | 8.34045 |
| Retainer, Guide Bushing, HT400 | 12 | 6 | 316.21096 | 316.21096 | 316.23953 | 316.24043 | 316.24043 |
| | | | | | | | |
| | | | | | | | |
| Plunger/cylender Head Cover Subassembly | | | | | | | |
| | | | Plunger Size |
| | Loc | Qty | 3-3/8 inch | 4-inch | 4-1/2 inch | 5-inch | 6-inch |
| Retainer, Cover HT-400TM | 1 | 6 | 316.2102. | 316.2102. | 316.2202. | 316.2502. | 316.2506. |
| Cover, Cylinder Head, HT-400TM | 2 | 3 | 316.2107. | 316.2107. | 316.2207. | 316.2407. | 316.2507. |
| Gasket, 4 Discharge Valve & Cylinder Head Cover | 3 | 6 | 316.21052. | 316.21052. | 316.22052. | 316.25052. | 316.25074. |
| Ring, Spacer, Discharge Valve & Cylinder Head Cover | 4 | 6 | 316.21051. | 316.21051. | 316.22051. | 316.25051. | 316.25073. |
| Nose, Plunger, HT-400TM | 5 | 3 | 316.2131. | 316.2231. | 316.2331. | 316.2331. | 316.2331. |
| Seal, Plunger Nose Assembly, HT-400TM | 6 | 3 | 316.2130. | 316.2230. | 316.2330. | 316.2330. | 316.2330. |
| Plunger, Hard Surface, L-Spacer, HT-400TM | 7 | 3 | 316.21026. | 316.22294. | 316.23085. | 316.24296. | 316.25162. |
| Tie Rod, Plunger, HT-400TM | 8 | 3 | 316.21028. | 316.21028. | 316.21028. | 316.25165. | 316.25165. |
| Adapter, Pushrod, HT-400TM, Two Piece Nose | 9 | 3 | 316.21059. | 316.22302. | 316.23089. | 316.24336. | 316.25172. |
| | | | | | | | |
| | | | | | | | |
| Fluid-end/flange discharge section subassembly | | | | | | | |
| | | | Plunger Size | | |
| | Loc | Qty | 3-3/8 inch | 4-inch | 4-1/2 inch | | |
| Flange, discharge, HT-400TM, BLANK | 1 | 1 | | 316.22980. | 316.22980. | | |
| Flange, discharge, HT-400TM, CURVED, Rright Hand | 1a | 1 | 316.21676. | 316.23019. | 316.23019. | | |
| Flange, discharge, HT-400TM, CURVED, Left Hand | 1b | 1 | 316.21677. | 316.23017. | 316.23017. | | |
| Seal, Discharge passage,HT-400TM | 2 | 6 | 315.27117. | 316.2547. | 316.2547. | | |
| Nut, 1-14NF, Internal Wrenching, 1.03 TL | 3 | 4 | 316.11621. | 316.11621. | 316.11621. | | |
| Stud, HT-400TM Fluid End To Thick Discharge Flange | 4 | 4 | 316.23013. | | 316.23013. | | |
| Bolt, Tie, 1.375-12 UNF×32.4 in.,Top, Fluid End, HT-400TM, TC | 5 | 1 | 316.27488. | 316.27488. | 316.27488. | | |
| Nut, Top Tie Bolt, HT-400TM, TC | 6 | 2 | 316.25501. | 316.25501. | 316.25501. | | |
| Washer, Hardened,2.31 O.D ×1.43I.D.,For Top Tie Boldt, | 7 | 2 | 316.22493. | 316.22493. | 316.22493. | | |
| Spacer, Inner, Discharge Passage Seal,HT-400TM | 8 | 2 | 316.2145. | 316.2545. | 316.2545. | | |
| Fluid End Section, HT-400TM PUMP,Not Sleeved | 9 | 3 | 316.21951. | 316.22982. | 316.23951. | | |
| Nut, Elastic, Stop,3/4-in.,16 NF | 10 | 2 | 70.32760. | | 70.32760. | | |
| | | | | | | | |
| Packing Subassembly |
| | | | Plunger Size |
| | Loc | Qty | 3-3/8 inch | 4-inch | 4-1/2 inch | 5-inch | 6-inch |
| Adapter, Header | 1 | 3 | 316.21503 | 316.22503 | 316.23503 | 316.24503 | 316.27503 |
| Ring Header | 2 | 3 | 316.21501 | 316.22501 | 316.23501 | 316.24501 | 316.27501 |
| Packign Set, 4-in.x 5-in, x 1/2-in. Stock, 3 Rings, Hard, Acid Service | 3 | 1 | 316.21525 | 316.22525 | 316.23525 | 316.24525 | 316.27525 |
| Ring, Backup, Packing, 4-in x 5-in. | 4 | 3 | 316.21393 | 316.22393 | 316.23393 | 316.24393 | 316.27393 |
| Carrier, Seal and Packing, 4-in | 5 | 3 | 316.21396 | 316.22396 | 316.23396 | 316.24396 | 316.27396 |
| Seal, Lube, Packing, WQ, 4-in x 4-1/2-in. x 9/16-in | 6 | 3 | 316.21395 | 316.22395 | 316.23395 | 316.24395 | 316.27395 |
| O-Ring, 90D, 5-in. x 4 3/4-in.x 1/8-in | 7 | 3 | 8.34040 | 8.34045 | 8.34049 | 8.34053 | 8.34058 |
| CONTINENTAL EMSCO FC-2200 FLUID END MODULE & ACCESSORIES |
| ITEM # | PART # | DESCRIPTION | QTY PER PUMP |
| - | 0-6323-0100-20 | ASSY, FLUID END COMPLETE (INCLUDES DISCHARGE MANIFOLD) | 1 |
| 1 | 0-6323-0108-00 | MODULE, DISCHARGE STUDDED | 3 |
| 2 | 0-6323-0109-00 | MODULE, SUCTION STUDDED | 3 |
| 3 | 0-6323-0087-90 | RETAINER, THREADED | 6 |
| 4 | 0-6323-0086-90 | RING, THREADED | 6 |
| 5 | 0-6323-0083-00 | COVER, VALVE POT | 6 |
| 6 | 0-6323-0103-00 | GUIDE W/ BUSHING, VALVE | 6 |
| 7 | 0-6323-0126-00 | HANDLER, VALVE POT | 6 |
| 8 | 0-6323-0107-20 | COVER, LINER END | 3 |
| 9 | 0-6323-0129-00 | DISC, BAFFLE | 3 |
| 10 | 0-6323-0085-00 | MANIFOLD, SUCTION | 1 |
| 11 | 0-6316-0105-95 | FLANGE, SUCTION | 1 |
| 12 | 0-6317-0074-95 | FLANGE, BLIND | 1 |
| 13 | 0-6323-0084-10 | DISCHARGE MANIFOLD, 7500 PSI | 1 |
| 14 | 0-6323-0097-90 | WEAR PLATE | 3 |
| 15 | 0-6323-0096-00 | RING, LINER THREAD | 3 |
| 16 | 0-6323-0099-00 | LINER LOCK | 3 |
| 17 | 0-6323-0093-00 | RETAINER, VALVE GUIDE | 6 |
| 18 | 0-6323-0128-00 | SEAL, SUCTION TO DISCHAGE MODULE | 3 |
| 19 | 0-6323-0127-00 | SEAL, WEAR PLATE & LINER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS) | 6 |
| 20 | 0-7602-1600-47 | O-RING (LINER LOCK RING) | 3 |
| 21 | 7817600456 | O-RING (SUCTION MANIFOLD) | 3 |
| 22 | 0-7602-1600-61 | O-RING (SUCTION MANIFOLD TO F.E.) | 3 |
| 23 | 0-7602-1600-30 | O-RING (DISCHARGE MANIFOLD TO F.E.) | 3 |
| 24 | 0-7501-0051-00 | SCREW, RETAINER | 24 |
| 25 | 7822095 | WIRE, SAFETY SST | 72 |
| 26 | 0-6323-0101-00 | RING, LINER LOCK | 3 |
| 27 | 7000534 | SCREW, SUCTION FLANGE HEX HD | 36 |
| 28 | 0-7601-0630-20 | NUT, HEX 1" - 8 | 36 |
| 29 | 0-6323-0125-00 | SEAL, VALVE POT COVER | 6 |
| 30 | 0-7601-0333-30 | SCREW, SUCTION MANIFOLD TO F.E. | 18 |
| CONTINENTAL EMSCO FC-1600 7500 PSI FLUID END MODULE & ACCESSORIES |
| | | | |
| ITEM # | PART # | DESCRIPTION | QTY PER PUMP |
| - | 0-6316-0452-10 | ASSY, COMPLETE FLUID END (INCLUDES MANIFOLDS) | 1 |
| 1 | 0-6316-0610-01 | MODULE, DISCHARGE STUDDED | 3 |
| 2 | 0-6316-0611-00 | MODULE, SUCTION STUDDED | 3 |
| 3 | | STUD, THREADED RING | |
| 4 | | NUT, THREADED RING AND DISCHARGE MANIFOLD STUD | |
| 5 | | STUD, SUCTION TO DISCHARGE MODULE | 6 |
| 6 | | NUT, SUCTION TO DISCHARGE MODULE AND POWER FRAME STUD | 6 |
| 7 | | STUD, DISCHARGE MANIFOLD | |
| 8 | | STUD, POWER FRAME | |
| 9 | 0-7601-0342-29 | CAPSCREW, SPACER FLANGE | 24 |
| 10 | 0-6316-0614-00 | THREADED RETAINER | 6 |
| 11 | 0-6316-0615-00 | THREADED RING | 6 |
| 12 | 0-7601-0040-11 | EYEBOLT, 3/4 X 4.50 | 6 |
| 13 | 0-6316-0616-00 | VALVE POT COVER | 6 |
| 14 | 0-6316-0585-00 | VALVE GUIDE | 6 |
| 15 | 0-6323-0093-00 | RETAINER, VALVE GUIDE | 6 |
| 16 | | CAPSCREW, VALVE GUIDE RETAINER | |
| 16A | | LOCK WASHER, VALVE GUIDE RETAINER CAPSCREW | |
| 17 | 0-6316-0583-00 | BUSHING, VALVE GUIDE | 6 |
| 18 | 0-6316-0092-00 | GASKET, VALVE COVER | 6 |
| 19 | 0-7601-0820-10 | DOWEL PIN | 12 |
| 20 | 0-7602-1600-61 | O-RING (SUCTION MANIFOLD TO F.E.) | 3 |
| 21 | 0-6316-0565-00 | GASKET, FE MODULE & WEAR PLATE | 6 |
| 22 | 0-7602-1600-25 | O-RING (DISCHARGE TO F.E.) | 3 |
| 23 | 0-6316-0566-01 | DISCHARGE MANIFOLD (NOT SHOWN) | 1 |
| 24 | 0-6316-0613-00 | SPACER FLANGE | 3 |
| 25 | 0-6316-0367-20 | LINER LOCK | 3 |
| 26 | 0-6316-0668-00 | WEAR PLATE | 3 |
| 27 | 0-6316-0523-00 | SUCTION MANIFOLD (NOT SHOWN) | 1 |
| 28 | 0-7601-0333-30 | CAPSCREW, SUCTION MANIFOLD | 18 |
| Item | Description | Part No. |
| | Complete Assembly | 8476-A |
| 1 | Threaded Flange | 4476 |
| 2 | Screw Gland | 4597 |
| 3 | Plug Assembly w/Guide & Bushing | 4676-2A |
| 4 | Valve Guide | 4776 |
| 5 | Valve Guide Bushing | 4700-I |
| 6 | Valve Guide Screw | 4016-98 |
| 7 | Valve Cover Stud w/Nut | 4015-54 |
| 8 | Power End Stud w/Nut | 4015-95 |
| 9 | Liner Retainer Capscrew | 4017-65 |
| 10 | Liner Retainer Flange | 6476 |
| 11 | Liner Retainer Nut | 6576 |
| 12 | Suction Module Stud w/Nut | 4018-17 |
| 13 | Suction Module (Studded) | 8476-2 |
| 14 | Discharge Module (Studded) | 8476-1 |
| 15 | Dowel Pin | 8488-5 |
| 16 | Wear Plate | 8476-3 |
| 17 | Valve Cover Plug Seal | P-107 |
| 18 | Module & Wear Plate Seal | 2988 |
| 19 | Piston Rod | 1286-32 |
| 20 | Sub Rod | 1286-1 |
| 21 | Rod Clamp w/Spray System | 1286-CW |
| Item | Description | Part No. |
| | Complete Assembly | 8488-1 |
| 1 | Discharge Module | 8488-1 |
| 2 | Suction Module | 8488-2 |
| 3 | Screw Gland | 4575 |
| 4 | Threaded Flange | 4475 |
| 5 | Wear Plate | 8488-4 |
| 6 | Plug Assembly w/Guide & Bushing | 4675-1A |
| 7 | Liner Retainer Flange | 6488-1 |
| 8 | Liner Retainer Nut | 6588-1 |
| 9 | Module Gasket | 2988 |
| 10 | Valve Cover Plug Seal | P-129 |
| 11 | Valve Guide Bushing | 4700-I |
| 12 | Valve Guide | 4775 |
| 13 | Valve Cover Stud w/Nut | 4015-2 |
| 14 | Power End Stud w/Nut | 4016-96 |
| 15 | Liner Retainer Capscrew | 4017-4 |
| 16 | Suction Module Stud w/Nut | 4016-97 |
| 17 | Wear Plate Gasket | 2974-I |
| 18 | Liner Retainer Screw Set | 8488-7 |
| 19 | Dowel Pin | 8488-5 |
| 20 | Discharge Manifold Stud | 4016-3 |
| 21 | Valve Guide Screw | 4018-88 |
| 22 | Piston Rod | 1290-25 |
| 23 | Sub Rod | 1290-1 |
| 24 | Piston Rod Connecting Stud | 1290-2 |
| 25 | Rod Clamp w/Spray System | 1290-CW |
