MP16 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, MP5 MUD PUMP, MP10 MUD PUMP, MP13 MUD PUMP

Ask Lasest Price
Brand Name :	WEATHERFORD
Model Number :	MP10
Certification :	API
Price :	40000 USD
Payment Terms :	T/T, L/C
Supply Ability :	50 SETS PER MONTH
Delivery Time :	IN STOCK

Add to Cart

Product Details
Company Profile

MP16 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, MP5 MUD PUMP, MP10 MUD PUMP, MP13 MUD PUMP

NATIONAL 12-P-160
FLUID END MODULE & ACCESSORIES

ITEM	PART NUMBER	DESCRIPTION	QTY/PUMP
		FLUID END MODULE COMPLETE ASSEMBLY
1	TS-1292240	MODULE, STUDDED FLUID END DISCHARGE (INCLUDES ITEM 2-10)	3
2	TS-1292241	DISCHARGE MODULE ONLY	3
3	TS-6300220	NUT, POWER FRAME STUD	24
4	TS-2408029	STUD, POWER FRAME	24
5	TS-6300180	NUT, LINER BUSHING STUD	18
6	TS-2408028	STUD, LINER BUSHING	18
7	TS-6300281	NUT, DISCHARGE TO SUCTION MODULE STUD	18
8	TS-2408033	STUD, DISCHARGE MODULE TO SUCTION MODULE	18
9	TS-6300240	NUT, THREADED RING STUD	36
10	TS-2408027	STUD, THREADED RING	36
11	TS-1292243	MODULE, STUDDED FLUID END SUCTION (INCLUDES ITEM 12,13,14 )	3
12	TS-1292244	SUCTION MODULE ONLY	3
13	TS-6300240	NUT, THREADED RING STUD	36
14	TS-2408027	STUD, THREADED RING	36
15	TS-1292165	BUSHING, LINER	3
16	TS-1292174	RETAINER, SEAL	6
17	TS-1292172	CAP, VALVE COVER (THREADED)	6
18	TS-1292178	SCREW, ADJUSTING WEDGE	6
19	TS-1292171	WASHER, WEDGE ADJUSTING SCREW	6
20	TS-6300182	NUT, WEDGE ADJUSTING SCREW	6
21	TS-1292176	RING, THREADED	6
22	TS-G1292268	ASSEMBLY, WEDGE (INCLUDES ITEM 18)	6
23	TS-1540127	GASKET, VALVE COVER	6
24	TS-1292140	RETAINER, VALVE GUIDE BUSHING	6
25	TS-1292141	BUSHING, VALVE GUIDE	6
26	TS-6511416	PIN, DOWELL	6
27	TS-1292266	PLATE, WEAR	3
28	TS-1292252	CONNECTOR, DISCHARGE	2
29	TS-700030711	CAPSCREW, DISCHARGE CONNECTOR	16
30	N/A	WASHER, LOCK	16
31	TS-1292253	ADAPTER, DISCHARGE CONNECTOR	2
32	TS-2410031433	SEAL, DISCHARGE CONNECTOR TO DISCHARGE ADAPTER	2
33	TS-2410031437	SEAL, DISCHARGE CONNECTOR & DISCHARGE ADAPTER	4
34	TS-1292166	ASSEMBLY, LINER CLAMP	3
35	TS-700049110	CAPSCREW, LINER CLAMP	6
36	TS-6309140	NUT, LINER CAPSCREW	6
37	TS-1292169	PIN, CONNECTOR	3
38	TS-1292168	CONNECTOR, LINER CLAMP	3
39	TS-2408015	STUD, TOP TAPER LOCK (FOR BLIND RING AND WELD NECK FLANGES)	16
40	TS-6300240	NUT, STUD (BLIND RING AND WELD NECK FLANGES)	16
41	TM12P-STUDSSET		3
42	TM12P-SEALKIT

MP16 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, MP5 MUD PUMP, MP10 MUD PUMP, MP13 MUD PUMP

OILWELL A-1700PT-L
FLUID END MODULE & ACCESSORIES

ITEM	PART#	DESCRIPTION	QTY
	TS-FEMA17DISSW	MODULE,STUDDED DISCHARGE(INCLUDES ITEMS 1,3-11)	3
1	TS-FEMA17DISSW	DISCHARGE MODULE ONLY	3
	TS-FEMA17SUCSW	MODULE,STUDDED SUCTION (INCLUDES ITEMS 2,9-10)	3
2	TS-FEMA17SUCSW	SUCTION MODULE ONLY	3
3	TS-OWA17DMSSW	STUD,DISCHARGE MANIFOLD	12
4	TS-0-7601-0630-28	NUT, DISCHARGE MANIFOLD STUD	12
5	TS-OWA17PFSSW	STUD,POWER FRAME	12
6	TS-75510126	NUT,POWER FRAME STUD	12
7	TS-OWA17DSUCSSW	STUD,DISCHARGE TO SUCTION MODULE	18
8	TS-0-7601-0630-17	NUT,FOR ABOVE STUDE	18
9	TS-OWA17TRSSW	STUD, THREADED RING	72
10	TS-6300200	NUT, THREADED RING STUD	72
11	TS-6511416	PIN,DOWELL	6
12	TS-OWA17LRPLATESW	PLATE,LINER RETAINER	3
13	TS-PEP68	CAPSCREW,LINER RETAINER PLATE	24
14	TS-1290344	SEAL,DISCHARGE TO SUCTION MODULE	3
15	TS-20100008	SEAL,WEAR PLATE–RUBBER(SEE DATASHEET FOR ALTERNATE MATERIALS)	3
16	TS-10300184	PLATE WEAR	3
17	TS-OWA17LLNSW	NUT,LINER LOCK	3
18	TS-07207129	SEAL,VALVE COVER-RUBBER(SEE DATASHEET FOR ALTERNATE MATERIALS)	6
19	TS-PEP73	SCREW,VALVE COVER RETAINER	12
20	TS-OWA17VGASW	GUIDE,VALVE(INCLUDES ITEMS 20 & 22)	6
21	TS-OWA17VCASSYSW	PLUG,VALVE COVER(INCLUDLES ITEMS 19-22)	6
22	TS-PZ789VGI*	BUSHING,VALVE GUIDE	6
23	TS-OWA17FLGSW	RING,THREADED	6
24	TS-OWA17CASW	CAP,THREADED	6
25	TS-10300201	GASKET,SUCTION MANIFOLD	3
26	TS-99609345	GASKET,DISCHARGE MANIFOLD	3
27	TS-75634382	CAPSCREW,SUCTION MANIFOLD	24
28	TS-PEP90	SETSCREW,LINER RETAINER	9

MP16 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, MP5 MUD PUMP, MP10 MUD PUMP, MP13 MUD PUMP

NATIONAL FB1300/1600(SW)
FLUID END MODULE & ACCESSORIES

ITEM	PART NUMBER	DESCRIPTION	QTY/PUMP
		FLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEM 1-27)	3
1	TS-84901D	MODULE, STUDDED DISCHARGE (INCLUDES ITEMS 1, 3-10, 11)	3
2	TS-84902S	MODULE, STUDDED SUCTION (INCLUDES ITEMS 2, 12, 13)	3
3	TS-4016-97	STUD, DISCHARGE MODULE TO SUCTION MODULE	18
4	TS-0-7601-0630-17	NUT, DISCHARGE TO SUCTION MODULE STUD	18
5	TS-4015-2	STUD, THREADED RING	36
6	TS-6300200	NUT, THREADED RING STUD	36
7	TS-4016-9	STUD, POWER FRAME	18
8	TS-0-7601-0630-17	NUT, POWER FRAME STUD	18
9	TS-4017-46	STUD, DISCHARGE MANIFOLD	12
10	TS-0-7601-0630-24	NUT, DISCHARGE MANIFOLD STUD	12
11	TS-4017-36	CAPSCREW, LINER RETAINER FLANGE (SOCKET HEAD)	24
12	TS-4015-2	STUD, THREADED RING	36
13	TS-6300200	NUT, THREADED RING STUD	36
14	TS-8488-5	PIN, DOWELL	6
15	TS-2988	SEAL, SUC TO DISCH MOD & WEAR PLATE - RUBBER (SEE DATASHEET FOR ALT MATLS)	6
16	TS-8422-3	RING, LINER RETAINER PILOT	3
17	TS-8490-3	PLATE, LINER WEAR	3
18	TS-6490-3	FLANGE, LINER RETAINER	3
19	TS-6590-1	NUT, LINER LOCK	3
20	TS-P-129	GASKET, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS)	6
21	TS-4016-99	STUD,VALVE GUIDE	12
22		NUT,STUD VALVE GUIDE	12
23	TS-4700-I	BUSHING, VALVE GUIDE	6
24	TS-4775-2R	GUIDE, VALVE (INCLUDES ITEM 20)	6
25	TS-4675-2A	PLUG, VALVE COVER	6
26	TS-4475	RING, THREADED	6
27	TS-4575	CAP, VALVE COVER (THREADED)	6

Weatherford offers a full line of premium-quality mud pumps based on proven and

simple-to-maintain designs that are accepted around the world. Each pump comes with

exceptional service and support that only a true global provider like Weatherford can

promise. When you factor in our competitive pricing and off-the-shelf availability of pumps

and parts, it’s clear that Weatherford has raised the bar for mud pumps.

Weatherford is building one of the world’s leading reciprocating pump organizations by giving you more pump for your money.

We build in extra-value features that don’t cost extra and give you the lasting value of pump components built for maximum

reliability and service life.

Most importantly, our people bring invaluable experience and dedication to your application. They will help you choose from

our broad range of pumps and accessories and deliver them to you faster than anyone else in the industry.

MP16 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, MP5 MUD PUMP, MP10 MUD PUMP, MP13 MUD PUMP

Description	MP-5 Mud Pump	MP-10 Mud Pump	MP-13 Mud Pump	MP-16 Mud Pump
Liner of Crosshead Upper	1198383	1124876	1134260	1134260
Liner of Crosshead Lower	1198383	1124887	1134268	1134268
Pin of Crosshead	1198389	0908381	908404	908404
Extension Rod	1198419	0908378	908402	908402
Crankshaft	1198311	0908355	0908384	0908384
Crosshead	1198380	0908368	908399	908399
Pinion Shaft	1198346	1124723	1134026	1134026
Wear Ring of Pinion shaft	1198347	1124724	1134027	1134027
Seal, Oil	1198356	1124733	1844173	1844173
Double Oil Seal	1317783	1317770	1133825	1133825
Connecting Rod	1198309	0908362	0908427	0908427
Bull Gear	1198318	0908357	0908408	0908408
Stuffing Box	1198347	1124724	1134263	1134263
Bolt, Main Bearing	1198328	1280235	1133853	1133853
Bearing, Wrist Pin		0908364	908429	908429
Bearing, Pinion Shanft	1198357	0908356	0908397	0908397
Bearing, Eccentric	1198337	1280232	0908442	0908442
Bearing, Main	1198338	1280233	0908425	0908425

Description	F500 mud pump	F800 mud pump	F1000 mud pump	F1300/1600 mud pump
Liner of Crosshead Upper	RS11311.04.02	RS11308.04.002	RS11306.04.001	RS11309.04.002
Liner of Crosshead Lower	RS11311.04.02	RS11308.04.009	RS11306.04.002	RS11309.04.013
Pin of Crosshead	RS11311.04.13	RS11308.04.010	RS11306.04.011	RS11309.04.011
Extension Rod	RS11311.04.06	RS11308.04.005	RS11306.04.007	RS11309.04.010
Crankshaft	RS11311.02.08.00	RS11308.02.08	RS11306.02.08	RS11309.02.008
Crosshead	RS11311.04.01	RS11308.04.001	RS11306.04.003	RS11309.04.001
Pinion Shaft	RS11311.03.02	RS11308.03.007	RS11306.03.007	RS11309.03.002
Wear Ring of Pinion shaft	RS11311.03.03	RS11308.03.002	RS11306.03.002	RS11309.03.003
Double Oil Seal	RS11311.04.09	RS11308.04.008	RS11306.04.014	RS11309.04.007
Oil Seal, Pinionshaft	RS11311.03.12	RS11308.03.011	RS11306.03.003	RS11309.03.011
Connecting Rod	RS11311.02.07	RS11308.02.006	RS11306.02.006	RS11309.02.006
Bull Gear	RS11311.02.10	RS11308.02.010	RS11306.02.010	RS11309.02.010
Stuffing Box	RS11311.04.05	RS11308.04.003	RS11306.04.006	RS11309.04.005
Bolt, Main Bearing	RS11311.02.04	RS11308.02.015	RS11306.02.015	RS11309.02.015
Bearing, Crosshead	5G354920Q	254735Q	5G254936Q	RS11309.04.015
Bearing, Pinion Shanft	4G32828H	4G32836H	4G32840H	RS11309.03.012
Bearing, Eccentric	92984QU	928/508QU	929/558.8QU	RS11309.02.017
Bearing, Main	3G3053738H	3G3003748HY	3G4053156H	RS11309.02.018

Description	A850PT	A1100PT	A1400PT	A1700PT
Liner of Crosshead Upper			10-300-141	10-300-141
Liner of Crosshead Lower			10-300-233	10-300-233
Pin of Crosshead			10-300-131	10-300-131
Extension Rod			10-300-142	10-300-142
Sub Rod			10-150-125	10-150-125
Crosshead			10-300-232	10-300-232
Pinion Shaft			10-301-004	10-301-004
Carrier, Bearing Left			10-300-024	10-300-024
Carrier, Bearing Right			10-300-024	10-300-024
Connecting Rod			10-300-071	10-300-071
Bull Gear			10-300-060	10-300-060
Crankshaft			10-301-013	10-300-154
Bearing, Crosshead			65-725-957	65-725-957
Bearing, Pinion Shanft			65-725-032	65-725-032
Bearing, Eccentric			65-725-936	65-725-936
Bearing, Main			65-725-034	65-725-034
Suction Manifold			10-300-193	10-300-193

All our fluid end parts are manufactured to API 7K quality standards.

Parts are available for these popular pump models:

BOMCO/Emsco Mud Pumps:F2200HL, F1600HL, F-1300, F-1600, FB1300, FB1600, F-800, F-1000, F-500, F-350, DB-550, DA-700, FA-1600/1300, FC-2200, D-300/500, D-375, D-700,

LS National Mud Pumps: 3NB-500C, 3NB1000C, 3NB1300C, 3NB1600

Ideco Mud Pumps: T-500, T-800, T-1000, T-1300, T-1600,

National Mud Pumps: 7P50, 8P80, 9P100, 10P130, 12P160, N1300, C-250, K-700, 14-P-220, E-700/G-1000, K-500, K-380, K-500A/700A, C-250/350, JWS-400,

Gardner Denver Mud Pumps: PZ7, PZ8/9, PZ10/11, FK-FXK, FY-FXD, FD-FXX, FG-GXG, FG-FXG, KG-KXG, FQ-FXQ, FF-FXF, FF-FXP,

Oilwell Mud Pumps: A-560/600-PT, A-850-PT/A-1100-PT, A-1700-PT/A-1400-PT

Wirth Mud Pump: TPK1000, TPK1600, TPK 2000,TPK2200

Russian Mud Pumps: UNBT-950, UNB-600, 8T-650, UNBT650, NBT600, UNB1180, UNB1180L, NB125, NB80, NB50, NB32

WEATHERFORD/Ellis Williams: E-447, E-2200

Drillmec Mud Pump: 9T1000, 12T1600, 7TS600, 7TS500, 9T800

Romania Mud Pump: 3PN-1000, 3PN-1600, 3PN-2000

And other brand spare parts for WIRTH, OPI, Ellis Williams, Wilson, Gaso, Skytop/Brewster.

MP16 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, MP5 MUD PUMP, MP10 MUD PUMP, MP13 MUD PUMP

1,Plunger Size 3.38” - 4.00” Valve Part No. P107185 Seat Part No. P107802

Insert Part No. P107186 Spring

2,Plunger Size 4.50” Valve Part No. P107181 Seat Part No. P107180

Insert Part No. P107182 Spring

3,Plunger Size 5.00” - 6.00” Valve Part No. P107188 Seat Part No. P107187

Insert Part No. P107189 Spring4P102382

SPM2000

1,Plunger Size 3.75" Plunge Part No 3P103887

2,Plunger Size 4.00" Plunge Part No 3P100339

3,Plunger Size 4.50" Plunge Part No 3P100654

4,Plunger Size" 5.00" Plunge Part No 3P100233

5,Plunger Size" 5.50 Plunge Part No 3P107060

6,Plunger Size" 5.75" Plunge Part No 3P107061

7,Plunger Size 6.00 Plunge Part No 3P107062

SPM

TWS 250 Plunger Size 1.75"-3" 3.25"-4"

TWS 400 Plunger Size 2 .50"-3" 3 .50"-4 .50”

TWS 500LW-600 Plunger Size 2 .75" 3"-4 .75"

TWS 600S Plunger Size 2 .50"-3" 3.50"-4 .50"

TWS 900 Plunger Size 3.50"-4"

TWS 1250LW Plunger Size 4"

OPI880 Plunger Size 3.75" 4.00” 4.5” 5.0:” 5.50” 5.75” 6.0”

TWS1000LW,TWS1300

Plunger Size 3.75" 4.00” 4.5” 5.0:” 5.50” 5.75” 6.0” 6.5 “ 6.75”

TWS1600 Plunger Size 3.5” 3.75” 4.0” 4.50” 5.0” 5.5” 5.75 “6.0”

TWS1800 Plunger Size 3.5” 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0”

TWS2250 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”

QWS 2000 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”

QWS 2500 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”

5.50” 5.75” 6.0”

TWS2250 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”

QWS 2000 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5”

QWS 2500 Plunger Size 3.75” 4.0” 4.5” 5.0” 5.50” 5.75” 6.0” 6.5

MP16 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, MP5 MUD PUMP, MP10 MUD PUMP, MP13 MUD PUMP

Brewster ® Mud Pumps B-550 • B-750 • B-1000 • 1100T • B-1300

Continental Emsco ® Mud Pumps F-350 • F-500 • F-650 • F-800 • F-1000 • FA-1300 • FB-1600 FB1600

Gaso ® Mud Pump 1563 • 1740-55 • 1844-60 • 2010-50 • 2200-49 • 2651 • 2652

Gardner Denver ® Mud Pumps

PAH • PZ-7 PZG • PZ-8 PZH • PZ-9 PZJ • PZ-10 PZK • PZ-11 PZL

Gardner Denver ® Well Service TEE • PE-5 • PA-8 • PAH • PJ-8 • TGF-225

Gardner Denver ® Continuous Duty GD-55T • GD-60T • GD-100T • GD-125T • GD-150T • GD-180T • GD-200T

Ideco ® Mud Pumps MM-200 • MM-300 • MM-500 • MM-500F • MM-550

Ideco ® Mud Pumps MM-550F • MM-700 • MM-700F • T-500

Ideco ® Mud Pumps T-500 • T-800 • T-1000 • T-1300 • T-1600

National ® J Series Mud Pumps J-30 • J-60 • J-100 • J-165 • J-275 • J-375 • J-625 • JWS-340 • JWS-400

National ® Mud Pumps K-280 • K-380 • K-500 • K-500A • K-700A

National ® P Series Mud Pumps 7P-50 • 8P-80 • 9P-100 • 10P-130 • 12-P-160 / 12P-160 / 12P160

Oilwell ® Mud Pumps A-350-PT • 560-PT • A-560-PT • 850-PT • A-850-PT • 1100-PT

Oilwell ® Mud Pumps A-1100-PT • 1400-PT • A-1400-PT • 1700-PT • A-1700-PT / A1700-PT

Oilwell ® Plunger Pumps C-323 through B-558 • SA-640-50 through SB-644-B

OPI ® Mud Pumps 350-D • 00-DL • 700-HDL • 1000-HDL

Wheatley ® Mud Pumps 1036 • 6070 • 7024 • 7036

Fluid End Modules

National® - Oilwell® - Continental Emsco® - Gardner Denver® - Ideco® - Skytop Brewster®

Pulsation Dampener

Hydril Type "K" Pulsation Dampener

Popular Mud Pump Spare Parts

NATIONAL 14-P-220 (7500 PSI) W/ FAST CHANGE VALVE COVERS FLUID END MODULE & ACCESSORIES
ITEM #	OEM PART #	DESCRIPTION	QTY PER PUMP
	80718020	ASSY, COMPLETE FLUID END W/ VALVE SERVICE & SUCTION MANIFOLD	1
1	1295601	MODULE, STUDDED FLUID END DISCHARGE (INCLUDES ITEMS 1, 3-10)	3
2	1295604	MODULE, STUDDED FLUID END SUCTION (INCLUDES ITEMS 2, 3-4)	3
3	2408049	STUD, VALVE COVER	84
4	6300240	NUT, VALVE COVER STUD	84
5	2408027	STUD, POWER FRAME	30
6	6300240	NUT, POWER FRAME STUD	30
7	2408047	STUD, LINER BUSHING	18
8	6300200	NUT, LINER BUSHING STUD	18
9	2408048	STUD, SUCTION TO DISCHARGE MODULE	18
10	6300320	NUT, SUCTION TO DISCHARGE MODULE STUD	18
11	2408014	STUD, DISCHARGE FLANGE	12
12	6300180	NUT, DISCHARGE FLANGE STUD	12
13	1295262	SPACER, STUDDED DISCHARGE (NOT SHOWN) INCLUDED ITEM# 11 AND 12	2
14	1295258	SEAL, DISCHARGE SPACER (NOT SHOWN)	2
15	7006609	CAPSCREW, DISCHARGE SPACER FLANGE	24
16	1295176	RING, THREADED F/C	6
17	1295172	CAP, VALVE COVER (THREADED) F/C	6
18	1292353	PULLER, SEAL RETAINER	6
19	1295174	RETAINER, SEAL	6
20	1540163	SEAL, VALVE COVER	6
21	1292140	HOLDER, VALVE GUIDE INSERT	6
22	1292141	INSERT, VALVE GUIDE	6
23	1540021	SEAL, SUCTION MANIFOLD	3
24	700048511	CAPSCREW, SUCTION MANIFOLD	24
25	2410031440	SEAL, DISCHARGE CONNECTOR & DISCHARGE ADAPTER	4
26	1295253	ADAPTER, DISCHARGE CONNECTOR	2
27	2410031438	SEAL, DISCHARGE CONNECTOR TO DISCHARGE ADAPTER	2
28	1295252	CONNECTOR, DISCHARGE	2
28A	1295175	RING, DISCHARGE CONNECTOR BACK UP	4
29	7619050	WASHER, DISCHARGE CONNECTOR CAPSCREW (NOT SHOWN)	16
30	700030711	CAPSCREW, DISCHARGE CONNECTOR	16
31	6511416	PIN, DOWELL	6
32	1295266	PLATE, WEAR	3
33	1295165	BUSHING, LINER	3
34	1295166	CLAMP COMPLETE, LINER (INCLUDES ITEMS 34A, 34B, 34C, 34D, 34E, 34F)	3
34A	1295167	CLAMP, LINER	3
34B	700049110	CAPSCREW, LINER CLAMP	6
34C	6309140	NUT, LINER CAPSCREW	6
34D	1292169	PIN, LINER CLAMP	6

MISSION "L" FOR NATIONAL 12-P-160 (7500 PSI WORKING PRESSURE) FLUID END MODULE & ACCESSORIES
ITEM #	OEM PART #	MISSION PART #	QTY PER PUMP
	80704032	ASSY, FLUID END COMPLETE (INCLUDES ITEMS 1-27) ENOUGH FOR 1 PUMP	1
	80704035	ASSY, FLUID END COMPLETE W/ BLAK-JAK LINER RETENTION SYSTEM	1
	80704038	ASSY, FLUID END COMPLETE W/ ROUGHNECK VALVES L/ LINER BUSHING & NUT (#'S 19, 20)	1
1	/80704000	MODULE, DISCHARGE STUDDED (INCLUDES ITEMS 1, 3-10)	3
2	80704001	MODULE, SUCTION STUDDED (INCLUDES ITEMS 2, 7-8)	3
3	80704002	STUD, DISCHARGE TO SUCTION MODULE	24
4	75510126	NUT, HEAVY HEX	24
5	80704003	THREADED RING	6
6	80704004	THREADED CAP	6
7	/80704005	VALVE COVER	6
8	80704006	DISCHARGE MANIFOLD (7500 PSI WORKING PRESSURE)	1
9	80702011	STUD, DISCHARGE MANIFOLD	12
10	0-7601-0630-24	NUT, DISCHARGE MANIFOLD STUD	12
11	12PVGASW	GUIDE, VALVE	6
12	PZ789VGI*	BUSHING, VALVE GUIDE	6
13	7007303	SCREW, VALVE GUIDE	12
13	PZ789VGI*	BUSHING, VALVE GUIDE	6
14	PEP75	CAPSCREW, LINER RETAINER	18
15	2408029
16	6300220	NUT, POWER FRAME STUD	30
17	PEP70	DOWELL PIN	6
18	80700014	STUD, THREADED RING	72
19	6300240	NUT, THREADED RING STUD	72
20		SUCTION MANIFOLD	1
21	1290344	SEAL, DISCH TO SUC & WEARPLATE - RUBBER (SEE DATASHEET FOR ALT MATLS)	6
22	7207119	SEAL, VALVE COVER - RUBBER (SEE DATASHEET FOR ALTERNATE MATERIALS)	6
23	99609235	SEAL, DISCHARGE MANIFOLD	3
24	1540851	SEAL, SUCTION MANIFOLD	3
25	700048511	CAPSCREW, SUCTION MANIFOLD	3
26	PP6021260SW	PLATE, WEAR	3
27	12PLASW	RETAINER, LINER FLANGE	3

MP16 MUD PUMP, BOMCO F1600 MUD PUMP, WEATHERFORD MUD PUMP, MP5 MUD PUMP, MP10 MUD PUMP, MP13 MUD PUMP

Inquiry Cart 0

Send your message to this supplier


*From:	Your email address is incorrect!
*To:	Qingdao National Premium Oilwell Machinery Co.,Ltd
*Subject:	Subject is empty!
*Message:	For the best results, we recommend including the following details: -Self introduction -Required specifications -Inquire about price/MOQ Characters Remaining: (0/3000) Please enter 20 to 3000 characters to contact this supplier!

Explore more Weatherford Mud Pumps products from this supplier

Find Similar Products By Category:

Textiles & Leather Products

Hot Searches:
