| No. | Drawing number | Name | Quantity | Remarks |
| LSF-1300/1600 drilling pump | | | |
| 1 | LSF3161-05.00 | Cylinder assembly | 3 | |
| 2 | LSF3161-05.02 | Cylinder lid flange | 3 | |
| 3 | LSF3161-05.03 | Cylinder lid | 3 | |
| 4 | LSF3161-05.04.00 | Inserted plate assembly | 3 | |
| 5 | LSF3161-05.05.00 | Valve rod guide (lower) | 3 | |
| 6 | LSF3161-05.06.00 | Valve rod plug | 3 | |
| 7 | LSF3161-05.07 | Locating disk | 3 | |
| 8 | LSF3161-05.08 | Cylinder lid sealing ring | 3 | |
| 9 | LSF3161-05.09 | Discharge pipe line | 1 | |
| 10 | LSF3161-05.10 | Valve spring | 6 | |
| 11 | GB/T3452.1-1992 | “O” type ring:95×5.3G | 3 | |
| 12 | LSF3161-05.11.00 | Valve assembly | 6 | |
| 13 | LSF3161-05.12 | Valve cover sealing ring | 3 | |
| 14 | LSF3161-05.13 | Valve cover | 3 | |
| 15 | LSF3161-05.14 | Cylinder liner sealing ring | 6 | |
| 16 | LSF3161-05.15 | Antiabrasive disk | 3 | |
| 17 | LSF3161-05.16 | Cylinder liner flange | 3 | |
| 18 | LSF3161-05.17.00 | Cylinder liner gland | 3 | |
| 19 | LSF3161-05.18 | Piston rod | 3 | |
| 20 | LSF3161-05.19.00 | Spray pipe assembly | 1 | |
| 21 | GB/T3452.1-1992 | “O” type ring:200×7.0G | 3 | |
| 22 | LSF3161-05.20 | Cylinder liner locking ring | 3 | |
| 23 | LSF3161-05.21 | Cylinder liner | 3 | |
| 24 | LSF3161-05.22.00 | Collar clamp assembly | 3 | |
| 25 | LSF3161-05.23 | Cylinder liner end cover | 3 | |
| 26 | LSF3161-05.24.00 | Piston assembly | 3 | |
| 27 | American standard | Bolt:7/8-9UNC-2A×60 | 18 | |
| 28 | LSF3161-05.25.00 | Suction pipe line | 1 | |
| 29 | LSF3161-05.26.00 | Gasket group | 4 | |
| 30 | LSF3161-05.40 | Gasket:39 | 30 | |
| 31 | LSF3161-05.27 | Valve rod guide (upper) | 3 | |
| 32 | LSF3161-05.28 | Stud:1 1/2-8UN-2A×265 | 16 | |
| 33 | LSF3161-05.01.06 | Nut:1 1/2-8UN-2B | 44 | |
| No. | Drawing number | Name | Quantity |
| LSF-1300/1600 drilling pump | | |
| 34 | LSF3161-05.29 | Retaining plate | 3 |
| 35 | LSF3161-05.30 | Bolt:3/8-16UNC-2A×20 | 12 |
| 36 | LSF3161-05.31 | Piston sealing ring | 3 |
| 37 | LSF3161-05.32.00 | Piston nut | 3 |
| 38 | GB/T3452.1-1992 | “O” type ring :190×7.0G | 3 |
| 39 | LSF3161-05.33.00 | Suction air tank | 1 |
| 40 | GB/T3452.1-1992 | “O” type ring:345×7.0G | 3 |
| 41 | LSF3161-05.34 | Suction flange(Ⅰ) | 1 |
| 42 | LSF3161-05.35 | Suction flange(Ⅱ) | 1 |
| 43 | American standard | Nut:1 1/16-8UN-2B | 36 |
| 44 | American standard | Bolt:1 1/16-8UN-2A×90 | 24 |
| 45 | GB/T4240-1993 | Stainless steel wire: φ1.6×1830 | 1 |
| 46 | American standard | Bolt:1 1/16-8UN-2A×90 | 12 |
| 47 | LSF3161-05.36 | Threaded plug:NPT1 1/2 | 1 |
| 48 | LSF3161-05.37 | Stud:1 1/2-8UN-2A×560 | 12 |
| 49 | Loa-Tie277 | Thread locking anaerobic colloid | |
| R1 | LSF3161-05.01.07 | Stud:1 1/4-8UN(12UNF)-2A×195 | 12 |
| R2 | LSF3161-05.01.08 | Nut:1 1/4-8UN-2B | 12 |
| R3 | LSF3161-05.01.04 | Stud:1 1/2-8UN(12UNF)-2A×170 | 30 |
| R4 | LSF3161-05.01.06 | Nut:1 1/2-8UN-2B | 30 |
| R5 | LSF3161-05.01.05 | Stud:1 1/2-UN(12UNF)-2A×120 | 30 |
| R6 | LSF3161-05.01.06 | Nut:1 1/2-8UN-2B | 30 |
| R7 | LSF3161-05.01.02 | Stud:1-8UNC(14UNS)-2A×185 | 36 |
| R8 | LSF3161-05.01.03 | Nut:1-8UNC-2B | 36 |
| No. | Drawing number | Name | Quantity |
| LSF-1300/1600 drilling pump | | |
| 1 | LSF3161-24.01.01 | Filter screen cover | 1 |
| 2 | GB/T3452.1-1992 | “O” type ring :165×7.0G | 1 |
| 3 | LSF3161-24.01.02 | Filter screen | 1 |
| 4 | LSF3161-24.02 | Outer shell | 1 |
| 5 | YK-150 | Dual scale anti-shock manometer 60MPa(8700psi) | 1 |
| 6 | LSF3161-22.01.03 | Manometer transition connection | 1 |
| 7 | LSF3161-22.01.00 | Manometer seating | 1 |
| 8 | LSF3161-25 | Flange | 1 |
| 9 | LSF3161-22.03.00 | Discharge cross piece | 1 |
| 10 | LSF3161-22.01.02 | Unstandard weld neck flange: two 9/16(φ65) | 4 |
| 11 | LSF3161-23 | Sealing packing ring R44 | 3 |
| 12 | 乐泰277 | Thread sealing anaerobic | |
| 13 | LSF3161-24.03 | Stud:1 1/2-8UN(12UNF)-2A×128 | 8 |
| 14 | LSF3161-24.04 | Nut:1 1/2-8UN-2B | 8 |
| 15 | LSF3161-22.02.00 | Safety valve connecting pipe | 1 |
| 16 | LSF3161-22.04 | stud:1 1/16-8UN-2A×170 | 16 |
| 17 | LSF3161-22.05 | Thick nut:1 1/16-8UN-2B | 32 |
| R1 | LSF3161-28.00 | JA-3 shear pin safety valve | 1 |
| R2 | LSF3161-27.00 | KB-75 air tank | 1 |
| No. | Drawing number | Name | Quantity |
| LSF-1300/1600 drilling pump | | |
| LSF3161-27.00 | KB-75air tank assembly | |
| 1 | LSF3161-27.01 | Sealing packing ring R39 | 1 |
| 2 | LSF3161-27.02 | Bottom plug | 1 |
| 3 | LSF3161-27.03.00 | Air bag | 1 |
| 4 | LSF3161-27.04.00 | Outer shell assembly | 1 |
| 5 | LSF3161-27.05 | Cover | 1 |
| 6 | LSF3161-27.06 | Tee NPT1/4 | 1 |
| 7 | LSF3161-27.07 | Connection NPT1/4 | 1 |
| 8 | LSF3161-27.08.00 | Manometer cover assembly | 1 |
| 9 | LSF3161-27.09.00 | Vent valve | 1 |
| 10 | Y-60 | Dual scale anti-shock manometer:25MPa(3630psi) | 1 |
| 11 | JZR3-L8 | Cut-off valve | 1 |
| 12 | LSF3161-27.10 | Washer | 1 |
| 13 | LSF3161-27.11.00 | Air tank hose assembly | 1 |
Type Parameter | 3NB500C | 3NB1000C | 3NB1300C | 3NB1600 |
| Input power rating | 368kW (500HP) | 735kW (1000HP) | 956kW (1300HP) | 1176kW (1600HP) |
| Rated pump speed | 95spm | 110spm | 120spm | 120spm |
| Stroke | 254mm | 305mm | 305mm | 305mm |
| Gear ratio | 3.821 | 3.833 | 3.81 | 3.81 |
| Rated speed of transmission shaft | 363rpm | 422rpm | 457rpm | 458rpm |
| Max. working pressure | 28.9MPa (295kgf/cm2) | 34.3MPa (350kgf/cm2) | 34.3MPa (350kgf/cm2) | 34.3MPa (350kgf/cm2) |
| Valve size | # 6 (API) | # 6 (API) | # 7 (API) | # 7 (API) |
| Max. liner size | Ø160 | Ø170 | Ø180 (Ø190 applicable) | Ø190 |
| Max. displacement | 24.26L/sec | 38L/sec | 46.6L/sec | 51.9L/sec |
| Max. liner pressure | 13.72MPa (140kgf/cm2) | 17.44MPa (178kgf/cm2) | 18.4MPa (188kgf/cm2) | 20.4MPa (208kgf/cm2) |
| Diameter of suction pipe | 254mm (10") | 305mm (12") | 305mm (12") | 305mm (12") |
| Diameter of discharge pipe | 100mm (4") | 100mm (4") | 100mm (4") | 100mm (4") |
| Overall dimensions | 4220 × 2640 × 2430 | 5170 × 2809 × 2530 | 4420 × 2998 × 2565 | 5040 × 3030 × 2615 |
| Weight (incl. accessories) | 15.940 tons | 21.450 tons | 24.8 tons | 26 tons |
3NB500C (107.15.00)
| Item | Drawing No. | Description | Qty | Unit weight kg | Remarks |
| 1 | 107.04.08 | Seal Ф190xФ178x8.6 | 6 | 0.28 | Liner pilot bushing |
| 2 | 107.04.110.10 | Sleeve | 6 | 0.07 | |
| 3 | 107.04.110.13 | Seal Ф210xФ180x15 | 6 | 0.13 | Suction manifold |
| 4 | 107.04.110.21 | Seal Ф155xФ140x10 | 4 | 0.18 | Both ends of discharge manifold |
| 5 | 107.04.110.45 | Gasket | 6 | 0.25 | Flange, suction manifold |
| 6 | 107.04.110.55 | Seal | 3 | 0.1 | Upper valve cover |
| 7 | 107.04.110.57 | Spring | 6 | 0.75 | |
| 8 | 107.04.120.00 | Locknut M39x3 | 6 | 0.9 | |
| 9 | 107.04.140.00 | Valve assy. (guide ring) | 48 | 10.74 | |
| 10 | 107.06.58.00 | Piston assembly Ф110 | 15 | 3.631 | |
| 11 | 107.06.60.00 | Piston assembly Ф120 | 15 | 3.92 | |
| 12 | 107.06.62.00 | Piston assembly Ф130 | 15 | 4.85 | |
| 13 | 107.06.64.00 | Piston assembly Ф140 | 15 | 5.53 | |
| 14 | 107.06.66.00 | Piston assembly Ф150 | 15 | 6.2 | |
| 15 | 107.06.68.00 | Piston assembly Ф160 | 15 | 6.66 | |
| 16 | 107.15.110.15 | Liner Ф110 | 6 | 60.51 | |
| 17 | 107.15.110.16 | Liner Ф120 | 6 | 55.05 | |
| 18 | 107.15.110.17 | Liner Ф130 | 6 | 49.09 | |
| 19 | 107.15.110.18 | Liner Ф140 | 6 | 42.64 | |
| 20 | 107.15.110.19 | Liner Ф150 | 6 | 35.78 | |
| 21 | 107.15.110.20 | Liner Ф160 | 6 | 28.32 | |
| 22 | 107.11.110.07 | Seal | 12 | 0.05 | |
| 23 | 107.14.110.08 | Valve cover | 3 | 12 | |
| 24 | 107.14.110.11 | Locking clip | 3 | 2.1 | |
| 25 | 107.14.124.00 | Spray hose | 3 | 0.97 | |
| 26 | 107.15.01.01 | Intermediate rod | 3 | 28.3 | |
| 27 | 107.15.97.00 | Single lip oil seal | 12 | 0.07 | Intermediate rod |
| 28 | 107.15.110.08 | Cover | 3 | 40 | |
| 29 | 107.15.110.22 | Nipple | 3 | 0.63 | |
| 30 | 107.15.110.23 | Piston rod | 6 | 10.6 | |
| 31 | 107.15.110.24 | Wear plate | 3 | 3.3 | |
| 32 | 107.15.110.29 | Locking plate | 3 | 2.47 | |
| 33 | 107.15.110.31 | Cage | 3 | 18 | |
| 34 | 107.15.110.32 | Seal | 3 | 01 | Liner, horizontal |
| 35 | 107.15.140.00 | Piston rod clamp | 3 | 10.4 | |
| 36 | 107.130.05 | Bolt 1"-8UN-2A | 3 | 0.24 | Dampener |
| 37 | 107.130.01.00-1 | diaphragm | 3 | 9.85 | Dampener |
| 38 | GB93-87 | Gasket 27 | 3 | 0.03 | Dampener |
| 39 | D4-4-66 | O-ring Ф140x5.7 | 3 | 0.02 | Dampener |
| 40 | 107.130.02 | Rubber plate | 3 | 4.4 | Dampener |
| 41 | 107.130.04 | End plate | 3 | 0.6 | Dampener |
| 42 | AQF-Ⅱ | Shear relief valve | 1 | 32 | |
| 43 | YK-100 | Anti-vibration pressure gauge 0~60MPa | 1 | 4 | |
12.2 3NB1000C (107.14.00)
| Item | Drawing No. | Description | Qty | Unit weight kg | Remarks |
| 1 | 107.04.09 | Ring Ф190xФ178x8.6 | 6 | 0.28 | Liner pilot bushing |
| 2 | 107.04.110.10 | Sleeve | 6 | 0.07 | |
| 3 | 107.04.110.13 | Ring Ф210xФ180x15 | 6 | 0.13 | Suction manifold |
| 4 | 107.04.110.21 | Ring Ф155xФ140x10 | 4 | 0.18 | Both ends of discharge manifold |
| 5 | 107.04.120.00 | Locknut M39x3 | 24 | 0.9 | |
| 6 | 107.04.140.00 | Valve assy. (guide ring) | 48 | 10.74 | |
| 7 | 107.04.110.55 | Seal | 3 | 0.1 | Upper valve cover |
| 8 | 107.04.110.57 | Spring | 6 | 0.75 | |
| 9 | 107.06.60.00 | Piston assembly Ф120 | 15 | 4.21 | |
| 10 | 107.06.62.00 | Piston assembly Ф130 | 15 | 4.85 | |
| 11 | 107.06.64.00 | Piston assembly Ф140 | 15 | 5.5 | |
| 12 | 107.06.66.00 | Piston assembly Ф150 | 15 | 6.2 | |
| 13 | 107.06.68.00 | Piston assembly Ф160 | 15 | 6.93 | |
| 14 | 107.06.70.00 | Piston assembly Ф170 | 15 | 7.76 | |
| 15 | 107.14.110.24 | Liner Ф120 | 6 | 70 | |
| 16 | 107.14.110.25 | Liner Ф130 | 6 | 63 | |
| 17 | 107.14.110.26 | Liner Ф140 | 6 | 56 | |
| 18 | 107.14.110.27 | Liner Ф150 | 6 | 48 | |
| 19 | 107.14.110.28 | Liner Ф160 | 6 | 40 | |
| 20 | 107.14.110.29 | Liner Ф170 | 6 | 31 | |
| 21 | 107.11.01.02 | Intermediate rod | 3 | 53.5 | |
| 22 | 107.11.97.00 | Single lip oil seal | 12 | 0.1 | Intermediate rod |
| 23 | 107.11.110.07 | Seal | 12 | 0.05 | |
| 24 | 107.11.110.39 | Piston rod | 6 | 18.5 | |
| 25 | 107.11.110.60 | Gasket | 6 | 0.25 | Flange, suction manifold |
| 26 | 107.11.126.00 | Nipple | 3 | 0.254 | |
| 27 | 107.14.110.04 | Cover | 3 | 53 | |
| 28 | 107.14.110.08 | Valve cover | 3 | 12 | |
| 29 | 107.14.110.10 | Locking plate | 3 | 3 | |
| 30 | 107.14.110.11 | Locking clip | 3 | 2.1 | |
| 31 | 107.14.110.12 | Cage | 3 | 18 | |
| 32 | 107.14.110.13 | Ring | 3 | 01 | Liner, horizontal |
| 33 | 107.14.110.16 | Wear plate | 3 | 3.5 | |
| 34 | 107.14.124.00 | Spray hose | 3 | 1 | |
| 35 | 107.14.125.00 | Piston rod clamp | 3 | 13 | |
| 36 | 107.130.02 | Rubber plate | 3 | 4.4 | Dampener |
| 37 | 107.130.04 | End plate | 3 | 0.6 | Dampener |
| 38 | 107.130.05 | Bolt 1"-8UN-2A | 3 | 0.24 | Dampener |
| 39 | 107.130.01.00-1 | Diaphragm | 3 | 9.85 | Dampener |
| 40 | GB93-87 | Gasket 27 | 3 | 0.03 | Dampener |
| 41 | D4-4-66 | O-ring Ф140x5.7 | 3 | 0.02 | Dampener |
| 42 | AQF-Ⅱ | Shear relief valve | 1 | 32 | |
| 43 | YK-100 | Anti-vibration pressure gauge 0~60MPa | 1 | 4 | |
12.3 3NB1300C(107.12.00)
| Item | Drawing No. | Description | Qty | Unit weight kg | Remarks |
| 1 | 107.06.62.00 | Piston assembly Ф130 | 15 | 4.85 | |
| 2 | 107.06.64.00 | Piston assembly Ф140 | 15 | 5.5 | |
| 3 | 107.06.66.00 | Piston assembly Ф150 | 15 | 6.2 | |
| 4 | 107.06.68.00 | Piston assembly Ф160 | 15 | 6.93 | |
| 5 | 107.06.70.00 | Piston assembly Ф170 | 15 | 7.76 | |
| 6 | 107.11.130.00 | Piston assembly Ф180 | 15 | 10.45 | |
| 7 | 107.12.110.06 | Liner Ф130 | 6 | 100 | |
| 8 | 107.11.110.33 | Liner Ф140 | 6 | 93 | |
| 9 | 107.11.110.34 | Liner Ф150 | 6 | 85 | |
| 10 | 107.11.110.35 | Liner Ф160 | 6 | 76 | |
| 11 | 107.11.110.36 | Liner Ф170 | 6 | 67 | |
| 12 | 107.11.110.37 | Liner Ф180 | 6 | 57 | |
| 13 | 107.04.110.13 | Ring Ф210xФ80x15 | 6 | 0.13 | Suction manifold |
| 14 | 107.04.110.21 | Ring Ф155xФ140x10 | 4 | 0.18 | Both ends of discharge |
| 15 | 107.04.120.00 | Locknut M39x3 | 24 | 0.9 | |
| 16 | 107.11.01.02 | Intermediate rod | 3 | 53.5 | |
| 17 | 107.11.97.00 | Single lip oil seal | 12 | 0.1 | Intermediate rod |
| 18 | 107.11.110.05 | Seal | 48 | 0.1 | Upper valve cover |
| 19 | 107.11.110.07 | Seal | 12 | 0.05 | |
| 20 | 107.11.110.16 | Spring | 48 | 0.78 | |
| 21 | 107.11.110.39 | Piston rod | 6 | 18.5 | |
| 22 | 107.11.110.40 | Cover | 3 | 53 | |
| 23 | 107.11.110.42 | Ring | 24 | 0.33 | Liner pilot bushing |
| 24 | 107.11.110.43 | Wear plate | 3 | 3.5 | |
| 25 | 107.11.110.52-1 | Locking clip | 3 | 2.48 | |
| 26 | 107.11.110.60 | Gasket | 6 | 0.25 | Flange, suction manifold |
| 27 | 107.11.110.65-1 | Locking plate | 3 | 3.1 | |
| 28 | 107.11.110.67 | Sleeve | 48 | 0.07 | |
| 29 | 107.11.110.68 | Seal | 48 | 0.09 | Liner, horizontal |
| 30 | 107.11.113.00-1 | Spray hose | 3 | 0.97 | |
| 31 | 107.11.114.00 | Piston rod clamp | 3 | 13 | |
| 32 | 107.11.140.00 | Valve assy. (guide ring) | 48 | 10.74 | |
| 33 | 107.11.330.00 | Cage | 3 | 16.5 | |
| 34 | 107.11.340.00 | Valve cover | 3 | 10.15 | |
| 35 | 107.12.116.00 | Spray cover | 3 | 2 | |
| 36 | 107.130.05 | Bolt 1"-8UN-2A | 3 | 0.24 | Dampener |
| 37 | 107.130.02 | Rubber plate | 3 | 4.4 | Dampener |
| 38 | 107.130.04 | End plate | 3 | 0.6 | Dampener |
| 39 | 107.130.01.00-1 | Diaphragm | 3 | 9.85 | Dampener |
| 40 | GB93-87 | Gasket 27 | 3 | 0.03 | Dampener |
| 41 | D4-4-66 | O-ring Ф140x5.7 | 3 | 0.02 | Dampener |
| 42 | AQF-Ⅱ | Shear relief valve | 1 | 32 | AQF-Ⅱ |
| 43 | YK-100 | Anti-vibration pressure gauge 0~60MPa | 1 | 4 | YK-100 |
12.4 3NB1600(107.11.00)
| Item | Drawing No. | Description | Qty | Unit weight kg | Remarks |
| 1 | 107.06.64.00 | Piston assembly Ф140 | 15 | 5.5 | |
| 2 | 107.06.66.00 | Piston assembly Ф150 | 15 | 6.2 | |
| 3 | 107.06.68.00 | Piston assembly Ф160 | 15 | 6.93 | |
| 5 | 107.06.70.00 | Piston assembly Ф170 | 15 | 7.76 | |
| 6 | 107.11.130.00 | Piston assembly Ф180 | 15 | 10.45 | |
| 7 | 107.11.135.00 | Piston assembly Ф190 | 15 | 12.15 | |
| 8 | 107.11.110.33 | Liner Ф140 | 6 | 93 | |
| 9 | 107.11.110.34 | Liner Ф150 | 6 | 85 | |
| 10 | 107.11.110.35 | Liner Ф160 | 6 | 76 | |
| 11 | 107.11.110.36 | Liner Ф170 | 6 | 67 | |
| 12 | 107.11.110.37 | Liner Ф180 | 6 | 57 | |
| 13 | 107.11.110.38 | Liner Ф190 | 6 | 47 | |
| 14 | 107.04.110.13 | Ring Ф210xФ180x15 | 6 | 0.13 | Suction manifold |
| 15 | 107.04.110.21 | Ring Ф155xФ140x10 | 4 | 0.18 | Both ends of discharge manifold |
| 16 | 107.04.120.00 | Locknut M39x3 | 24 | 0.9 | |
| 17 | 107.11.01.02 | Intermediate rod | 3 | 53.5 | |
| 18 | 107.11.97.00 | Single lip oil seal | 12 | 0.1 | Intermediate rod |
| 19 | 107.11.110.05 | Seal | 48 | 0.1 | Upper valve cover |
| 20 | 107.11.110.07 | Seal | 12 | 0.05 | |
| 21 | 107.11.110.16 | Spring | 48 | 0.78 | |
| 22 | 107.11.110.20 | Nipple | 6 | 0.254 | |
| 23 | 107.11.110.39 | Piston rod | 6 | 18.5 | 107.11.110.39 |
| 24 | 107.11.110.40 | Cover | 3 | 53 | |
| 25 | 107.11.110.42 | Ring | 24 | 0.33 | Liner pilot bushing |
| 26 | 107.11.110.43 | Wear plate | 3 | 3.5 | |
| 27 | 107.11.110.52-1 | Locking clip | 3 | 2.48 | 107.11.110.52-1 |
| 28 | 107.11.110.60 | Gasket | 6 | 0.25 | Flange, suction manifold |
| 29 | 107.11.110.65-1 | Locking plate | 3 | 3.1 | |
| 30 | 107.11.110.67 | Sleeve | 48 | 0.07 | |
| 31 | 107.11.110.68 | Seal | 48 | 0.09 | Liner, horizontal |
| 32 | 107.11.113.00-1 | Spray hose | 3 | 0.97 | |
| 33 | 107.11.114.00 | Piston rod clamp | 3 | 13 | |
| 34 | 107.11.140.00 | Valve assy. (guide ring) | 48 | 10.74 | |
| 35 | 107.11.330.00 | Cage | 3 | 16.5 | |
| 36 | 107.11.340.00 | Valve cover | 3 | 10.15 | |
| 37 | 107.130.02 | Rubber plate | 3 | 4.4 | Dampener |
| 38 | 107.130.04 | End plate | 3 | 0.6 | Dampener |
| 39 | 107.130.05 | Bolt 1"-8UN-2A | 3 | 0.24 | Dampener |
| 40 | 107.130.01.00-1 | Diaphragm | 3 | 9.85 | Dampener |
| 41 | GB93-87 | Gasket 27 | 3 | 0.03 | Dampener |
| 42 | D4-4-66 | O-ring Ф140x5.7 | 3 | 0.02 | Dampener |
| 43 | AQF-Ⅱ | Shear relief valve | 1 | 32 | |
| 44 | YK-100 | Anti-vibration pressure gauge 0~60MPa | 1 | 4 | |
| 45 | WBZ-25 | Gear oil pump | 1 | 54.5 | |
| 46 | P-B-63 | Low-pressure discharge-service valve | 1 | 1.5 | |
| 47 | XU-50x200 | Wire-wound oil filter | 1 | 4 | |
| 48 | Y-60 2.5G | Pressure gauge M14x1.5 0~1MPa | 1 | 0.25 | |
| 49 | Y-60 2.5G | Pressure gauge M14x1.5 0~2.5MPa | 1 | 0.25 | |
Parts are available for these popular pump models:
BOMCO/Emsco Mud Pumps:F-1300, F-1600, FB1300, FB1600, F-800, F-1000, F-500, F-350,
DB-550, DA-700, FA-1600/1300, FC-2200, D-300/500, D-375, D-700,
LS National Mud Pumps: 3NB-500C, 3NB1000C, 3NB1300C, 3NB1600
Ideco Mud Pumps: T-500, T-800, T-1000, T-1300, T-1600,
National Mud Pumps: 7P50, 8P80, 9P100, 10P130, 12P160, N1300, C-250, K-700, 14-P-220,
E-700/G-1000, K-500, K-380, K-500A/700A, C-250/350, JWS-400,
Gardner Denver Mud Pumps: PZ7, PZ8/9, PZ10/11, FK-FXK, FY-FXD, FD-FXX, FG-GXG, FG-FXG,
KG-KXG, FQ-FXQ, FF-FXF, FF-FXP,
Oilwell Mud Pumps: A-560/600-PT, A-850-PT/A-1100-PT, A-1700-PT/A-1400-PT
Wirth Mud Pump: TPK1000, TPK1600, TPK 2000,TPK2200
Russian Pumps: UNBT-950, UNB-600, 8T-650, UNBT650, NBT600, UNB1180, UNB1180L,
NB125, NB80, NB50, NB32
WEATHERFORD/Ellis Williams: E-447, E-2200
Drillmec: 9T1000, 12T1600, 7TS600, 7TS500, 9T800
Romania: 3PN-1000, 3PN-1600, 3PN-2000
And other brand spare parts for WIRTH, OPI, Ellis Williams, Wilson,
Gaso, Skytop/Brewster.
