| 序号 | 图 号 | 名 称 | 数量 | 序号 | 图 号 | 名 称 | 数量 |
| 1 | B-440343 | 阀盖 | 2 | 17 | B-440321 | 吸入阀导向架 | 1 |
| 2 | B-440323 | 阀盖堵头 | 1 | 18 | GB/T 3452.1 | O型密封圈φ150x5.3 | 1 |
| 3 | W-440.01.010 | 阀盖密封圈 | 1 | 19 | W0101 | 螺栓 3/4-10UNCX1 11/16 | 4 |
| 4 | W-440.01.004 | 阀弹簧 | 2 | 20 | W-440.01.008 | 缸套密封圈 | 1 |
| 5 | W-440.01.03.00 | 阀体总成(API #4) | 2 | 21 | W-440307 | 缸套 | 1 |
| 6 | W-440.01.002 | 阀座 | 2 | 22 | B-440322 | 缸套压盖 | 1 |
| 7 | GB/T 3452.1 | O型密封圈φ100x3.55 | 2 | 23 | W-440.01.007 | 锁紧螺母 | 1 |
| 8 | D-440342 | 阀盖法兰 | 2 | 24 | | 活 塞 | 1 |
| 9 | D-440003 | 液缸 | 1 | 25 | GB/T 3452.1 | O型密封圈φ25x3.55 | 1 |
| 10 | W-440.01.013 | 双头螺柱 3/4-10UNCX6 | 2 | 26 | B-440308 | 活塞杆 | 1 |
| 11 | NF2-3/4 | 螺母 3/4-10UNC-2B | 2 | 27 | W0105 | 螺母 9/16-12UNC | 2 |
| 12 | GB/T 3452.1 | O型密封圈φ47.5x5.3 | 1 | 28 | GB/T93 | 弹簧垫圈 14 | 2 |
| 13 | W-440.01.011 | 双头螺柱 7/8-9UNCX4 1/2 | 12 | 29 | B-440227.01 | 卡环 | 1 |
| 14 | NF2-7/8 | 螺母 7/8-9UNC | 12 | 30 | W0104 | 螺栓 9/16-12UNCX4 | 2 |
| 15 | B-440309 | 缸盖堵头 | 1 | 31 | W-440.01.006 | 螺母 1 1/8-8UN | 4 |
| 16 | W-440.01.001 | 阀侧盖密封圈 | 1 | 32 | W-440.01.005 | 双头螺柱 1 1/8-8UNX7 1/4 | 4 |
Parts are available for these popular pump models:
BOMCO/Emsco Mud Pumps:F-1300, F-1600, FB1300, FB1600, F-800, F-1000, F-500, F-350,
DB-550, DA-700, FA-1600/1300, FC-2200, D-300/500, D-375, D-700,
LS National Mud Pumps: 3NB-500C, 3NB1000C, 3NB1300C, 3NB1600
Ideco Mud Pumps: T-500, T-800, T-1000, T-1300, T-1600,
National Mud Pumps: 7P50, 8P80, 9P100, 10P130, 12P160, N1300, C-250, K-700, 14-P-220,
E-700/G-1000, K-500, K-380, K-500A/700A, C-250/350, JWS-400,
Gardner Denver Mud Pumps: PZ7, PZ8/9, PZ10/11, FK-FXK, FY-FXD, FD-FXX, FG-GXG, FG-FXG,
KG-KXG, FQ-FXQ, FF-FXF, FF-FXP,
Oilwell Mud Pumps: A-560/600-PT, A-850-PT/A-1100-PT, A-1700-PT/A-1400-PT
Wirth Mud Pump: TPK1000, TPK1600, TPK 2000,TPK2200
Russian Pumps: UNBT-950, UNB-600, 8T-650, UNBT650, NBT600, UNB1180, UNB1180L,
NB125, NB80, NB50, NB32
WEATHERFORD/Ellis Williams: MP-5, MP-8, MP-10, MP-13, MP-16, E-447, E-2200, E1600
Drillmec: 9T1000, 12T1600, 7TS600, 7TS500, 9T800,14T2200
Romania: 3PN-1000, 3PN-1600, 3PN-2000
序号 № | 代号 Обозначение | 名称 Наименование | 数量Ко-во |
| 1 | RS11309A.04.001 | 十字头 Ползун | 1 |
| 2 | RS11309.04.002 | 上导板 Верхняя направляющая | 1 |
| 3 | RS11309.04.003 | 垫片组 Группа шайбы | 8 |
| 4 | RS11309.04.004 | 调节垫片 Регулирующие шайбы | 2 |
| 5 | RS11309.04.005 | 填料盒 Сальниковая коробка | 1 |
| 6 | RS11309.04.006 | 油封环 Сальникоаое кольцо | 1 |
| 7 | RS11309.04.007 | 双唇密封圈 5X6.25X0.625” Уплотнительное кольцо | 2 |
| 8 | RS11309.04.008 | 锁紧弹簧 Запорная прцужина | 1 |
| 9 | RS11309.04.009 | 挡泥板 Грязьотбойный щит | 1 |
| 10 | RS11309.04.010 | 中间拉杆 Контрошток | 1 |
| 11 | RS11309A.04.011 | 十字头销 Полец ползуна | 1 |
| 12 | RS11309.04.012 | 密封垫 Уплотнительная прокладка | 1 |
| 13 | RS11309.04.013 | 下导板 нижняя направляющая | 1 |
| 14 | RS11309.04.014 | 十字头销挡板 Отбойный щит пальца ползуна | 1 |
| 15 | RS11309.04.015 | 十字头轴承 Подшипник ползуна | |
| 16 | RS11306.04.004 | 管接头 NPT 3/8 Штуцер | 2 |
| 17 | RS11309A.04.016 | 螺栓 M24X60 Болт | 2 |
| 18 | RS11309A.04.017 | 螺栓 M24X70 Болт | 6 |
| 19 | RS11306A.04.009 | 固定板 Фиксарующий щит | 8 |
| 20 | RS11309A.04.018 | 螺栓 M24X65 Болт | 8 |
| 21 | | 不锈钢丝 φ1.6 Нержевающая проволока | 按需 |
| 22 | GB/T 3452.1 | O型圈 125X7 О-кольцо | 1 |
| 23 | GB/T 3452.1 | O型圈 160X7 О-кольцо | 1 |
| 24 | GB/T 3452.1 | O型圈 190X3.55 О-кольцо | 1 |
| 25 | GB/T 5783 | 螺栓 M10X25 Болт | 4 |
| 26 | GB/T 93 | 弹性垫圈 10 Пружиная шайба 10 | 4 |
| 27 | GB/T 70.1 | 螺钉 M20X65 Винт | 8 |
| 28 | 242 | 螺纹厌氧锁固胶 Клей для крепления | 按需 |
注:本表中数量仅为一套十字头总成的数量,整台泵的数量需将表中数量乘3.
Количество в таблице для одного ползуна, на один буровой насос
количество на три.
| Description | F500 mud pump | F800 mud pump | F1000 mud pump | F1300/1600 mud pump |
| Liner of Crosshead Upper | RS11311.04.02 | RS11308.04.002 | RS11306.04.001 | RS11309.04.002 |
| Liner of Crosshead Lower | RS11311.04.02 | RS11308.04.009 | RS11306.04.002 | RS11309.04.013 |
| Pin of Crosshead | RS11311.04.13 | RS11308.04.010 | RS11306.04.011 | RS11309.04.011 |
| Extension Rod | RS11311.04.06 | RS11308.04.005 | RS11306.04.007 | RS11309.04.010 |
| Crankshaft | RS11311.02.08.00 | RS11308.02.08 | RS11306.02.08 | RS11309.02.008 |
| Crosshead | RS11311.04.01 | RS11308.04.001 | RS11306.04.003 | RS11309.04.001 |
| Pinion Shaft | RS11311.03.02 | RS11308.03.007 | RS11306.03.007 | RS11309.03.002 |
| Wear Ring of Pinion shaft | RS11311.03.03 | RS11308.03.002 | RS11306.03.002 | RS11309.03.003 |
| Double Oil Seal | RS11311.04.09 | RS11308.04.008 | RS11306.04.014 | RS11309.04.007 |
| Oil Seal, Pinionshaft | RS11311.03.12 | RS11308.03.011 | RS11306.03.003 | RS11309.03.011 |
| Connecting Rod | RS11311.02.07 | RS11308.02.006 | RS11306.02.006 | RS11309.02.006 |
| Bull Gear | RS11311.02.10 | RS11308.02.010 | RS11306.02.010 | RS11309.02.010 |
| Stuffing Box | RS11311.04.05 | RS11308.04.003 | RS11306.04.006 | RS11309.04.005 |
| Bolt, Main Bearing | RS11311.02.04 | RS11308.02.015 | RS11306.02.015 | RS11309.02.015 |
| Bearing, Crosshead | 5G354920Q | 254735Q | 5G254936Q | RS11309.04.015 |
| Bearing, Pinion Shanft | 4G32828H | 4G32836H | 4G32840H | RS11309.03.012 |
| Bearing, Eccentric | 92984QU | 928/508QU | 929/558.8QU | RS11309.02.017 |
| Bearing, Main | 3G3053738H | 3G3003748HY | 3G4053156H | RS11309.02.018 |
| Description | MP-5 Mud Pump | MP-10 Mud Pump | MP-13 Mud Pump | MP-16 Mud Pump |
| Liner of Crosshead Upper | 1198383 | 1124876 | 1134260 | 1134260 |
| Liner of Crosshead Lower | 1198383 | 1124887 | 1134268 | 1134268 |
| Pin of Crosshead | 1198389 | 0908381 | 908404 | 908404 |
| Extension Rod | 1198419 | 0908378 | 908402 | 908402 |
| Crankshaft | 1198311 | 0908355 | 0908384 | 0908384 |
| Crosshead | 1198380 | 0908368 | 908399 | 908399 |
| Pinion Shaft | 1198346 | 1124723 | 1134026 | 1134026 |
| Wear Ring of Pinion shaft | 1198347 | 1124724 | 1134027 | 1134027 |
| Seal, Oil | 1198356 | 1124733 | 1844173 | 1844173 |
| Double Oil Seal | 1317783 | 1317770 | 1133825 | 1133825 |
| Connecting Rod | 1198309 | 0908362 | 0908427 | 0908427 |
| Bull Gear | 1198318 | 0908357 | 0908408 | 0908408 |
| Stuffing Box | 1198347 | 1124724 | 1134263 | 1134263 |
| Bolt, Main Bearing | 1198328 | 1280235 | 1133853 | 1133853 |
| Bearing, Wrist Pin | | 0908364 | 908429 | 908429 |
| Bearing, Pinion Shanft | 1198357 | 0908356 | 0908397 | 0908397 |
| Bearing, Eccentric | 1198337 | 1280232 | 0908442 | 0908442 |
| Bearing, Main | 1198338 | 1280233 | 0908425 | 0908425 |
| CONTINENTAL EMSCO F-800, F-1000 |
| FLUID END MODULE & ACCESSORIES |
| | | |
| ITEM | PART NUMBER | DESCRIPTION | QTY/PUMP |
| | FLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEM 2-23) | 3 |
| 1 | TS-6999-0086-02 | FLUID END MODULE STUDDED (INCLUDES ITEM 2-8) | 3 |
| 2 | TS-6999-0087-02 | FLUID END MODULE (UNSTUDDED) | 3 |
| 3 | TS-7507-2205-00 | STUD FRAME | 18 |
| 4 | TS-7601-0630-17 | NUT (FOR ABOVE) | 18 |
| 5 | TS-7507-2150-00 | STUD, THREADED RING | 30 |
| 6 | TS-7601-0630-28 | NUT (FOR ABOVE) | 30 |
| 7 | TS-7507-2108-00 | STUD, DISCHARGE MANIFOLD | 12 |
| 8 | TS-7601-0630-24 | NUT (FOR ABOVE) | 12 |
| 9 | TS-6319-0026-00 | CAGE, LINER | 3 |
| 10 | TS-6319-0087-00 | GUIDE, LOWER VALVE (WITH BUSHING) | 3 |
| 11 | TS-6319-0089-00 | CLIP, LOCKING (FOR LOWER VALVE GUIDE) | 3 |
| 12 | TS-7602-2200-32 | GASKET, LINER/ CYLINDER HEAD (G-282) | 6 |
| 13 | TS-6319-0031-00 | PLUG, CYLINDER HEAD | 3 |
| 14 | TS-6999-0089-00 | RING, THREADED CYLINDER HEAD | 3 |
| 15 | TS-6319-0090-00 | CAP, THREADED CYLINDER HEAD | 3 |
| 16 | TS-6319-0076-00 | GASKET, VALVE COVER (G-740) | 3 |
| 17 | TS-7501-0051-00 | SCREW, RETAINER (UPPER) | 12 |
| 18 | TS-6397-0603-00 | RETAINER PLATE (UPPER) | 3 |
| 19 | TS-6397-0575-00 | GUIDE, UPPER VALVE | 3 |
| 20 | TS-6319-0027-00 | COVER, VALVE POT | 3 |
| 21 | TS-7602-1610-46 | GASKET, DISCHARGE MANIFOLD | 3 |
| 22 | TS-7602-1600-61 | GASKET, SUCTION MANIFOLD | 3 |
| 23 | TS-6316-0096-00 | BUSHING, LOWER VALVE GUIDE | 3 |
| 24 | TMF08-STUDSSET | F-800/1000 STUDS AND NUTS SET (INCLUDES 6 PCS TS-7507-2205-00, 6
PCS TS-7601-0630-17, 10 PCS TS-7507-2150-00, 10 PCS
TS-7601-0630-28, 4 PCS TS-7507-2108-00, 4 PCS TS-7601-0630-24) | 3 |
| 25 | TMF08-SEALKIT (07924503) | F-800/1000 MODULE SEAL KIT (INCLUDES ONE G-282, ONE G-740, ONE
TS-7602-1610-46, ONE TS-7602-1600-61) | 3 |
| CONTINENTAL EMSCO F-1300, F-1600 |
| FLUID END MODULE & ACCESSORIES |
| | | | |
| ITEM | TSC PART NUMBER | BAOJI PART NUMBER | DESCRIPTION | QTY/PUMP |
| TS-6316-0325-00 | AH36001-05.01A.00 | FLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEM 2-24, 26- 29) | 3 |
| 1 | TS-6316-0357-00 | | FLUID END MODULE STUDDED (INCLUDES ITEM 2-9) | 3 |
| 2 | TS-6316-0356-00 | | FLUID END MODULE ONLY (UNSTUDED) | 3 |
| 3 | TS-7507-2013-00 | T53-3008 | STUD, MODULE TO LINER CLAMP | 36 |
| 4 | TS-7601-0610-18 | AH36001-05.01A.03 | LINER CLAMP STUD NUT | 36 |
| 5 | TS-7507-2201-00 | T53-3005 | POWER FRAME STUD | 18 |
| 6 | TS-7507-2210-00 | T53-3007 | STUD, MODULE TO CYLINDER | 18 |
| 7 | TS-7601-0630-17 | T57-2011 | NUT (FOR ABOVE) | 72 |
| 8 | TS-7507-2108-00 | T53-3006 | STUD, MODULE TO DISC. MANIFOLD | 12 |
| 9 | TS-7601-0630-24 | T57-2009 | NUT (FOR ABOVE) | 12 |
| 10 | TSF16-05-04 | AH36001-05A.04.00 | RETAINER, LOWER VALVE | 3 |
| 11 | TSF16-05-05 | AH36001-05A.05.00 | LOWER VALVE GUIDE ASSEMBLY | 3 |
| 12 | TSF16-05-07 | AH36001-05A.07 | ALIGNMENT RING | 3 |
| 13 | TS-6316-0369-00 | AH36001-05.08 | GASKET, HEAD SEAL (G-801) | 3 |
| 14 | TS-6316-0364-00 | AH36001-05A.06.00 | PLUG, CYLINDER HEAD | 3 |
| 15 | TS-6316-0361-00 | AH36001-05.02 | RING, THREADED CYLINDER HEAD | 3 |
| 16 | TS-6316-0362-00 | AH36001-05.03 | CAP, THREADED CYLINDER HEAD | 3 |
| 17 | TS-6316-0092-00 | AH36001-05.13 | GASKET, VALVE COVER (G-741) | 3 |
| 18 | TS-7501-0051-00 | AH33001-05.15A | SCREW, RETAINER (UPPER) | 3 |
| 19 | TS-6397-0603-00 | AH33001-05.14 | PLATE, RETAINER (UPPER) | 12 |
| 20 | TS-6397-0575-00 | AH33001-05.12 | GUIDE, UPPER VALVE | 3 |
| 21 | TS-6316-0039-00 | AH36001-05.14A | COVER, VALVE POT | 3 |
| 22 | TS-6316-0373-00 | AH36001-05.15 | GASKET, LINER (G-800) | 6 |
| 23 | TS-6316-0365-00 | AH36001-05.16A | WEAR PLATE | 3 |
| 24 | TS-6316-0366-00 | AH36001-05.17 | RING, LINER THREADED | 3 |
| 25 | TS-6316-0367-00 | AH36001-05.18.00 | LINER LOCK | 3 |
| 26 | TS-7602-1600-25 | GB3452.1-82"O"ф95×5.3 | GASKET, DISCHARGE MANIFOLD | 3 |
| 27 | TS-7602-1600-61 | GB3452.1-82"O"ф185×7 | GASKET, SUCTION MANIFOLD | 3 |
| 28 | TS-F16-05-35 | AH36001-05.35B | STUD, | 12 |
| CONTINENTAL EMSCO FB-1300, FB-1600 |
| FLUID END MODULE & ACCESSORIES |
| | | |
| ITEM | PART NUMBER | DESCRIPTION | QTY/PUMP |
| TS-6316-0325-00 | FLUID END MODULE COMPLETE ASSEMBLY (INCLUDES ITEM 2-24, 26- 29) | 3 |
| 1 | TS-6316-0357-00 | FLUID END MODULE STUDDED (INCLUDES ITEM 2-9) | 3 |
| 2 | TS-6316-0356-00 | FLUID END MODULE ONLY (UNSTUDED) | 3 |
| 3 | TS-7507-2013-00 | STUD, MODULE TO LINER CLAMP | 36 |
| 4 | TS-7601-0610-18 | LINER CLAMP STUD NUT | 36 |
| 5 | TS-7507-2201-00 | POWER FRAME STUD | 18 |
| 6 | TS-7507-2210-00 | STUD, MODULE TO CYLINDER | 18 |
| 7 | TS-7601-0630-17 | NUT (FOR ABOVE) | 48 |
| 8 | TS-7507-2108-00 | STUD, MODULE TO DISC. MANIFOLD | 12 |
| 9 | TS-7601-0630-24 | NUT (FOR ABOVE) | 12 |
| 10 | TS-6316-0354-00 | GUIDE, LOWER VALVE (WITH BUSHING) | 3 |
| 11 | TS-6316-0096-00 | BUSHING, LOWER VALVE GUIDE | 3 |
| 12 | TS-6316-0360-00 | LOCKBOLT, LOWER VALVE GUIDE | 3 |
| 13 | TS-6316-0363-00 | ALIGNMENT RING | 3 |
| 14 | TS-6316-0369-00 | GASKET, HEAD SEAL (G-801) | 3 |
| 15 | TS-6316-0364-00 | PLUG, CYLINDER HEAD | 3 |
| 16 | TS-6316-0361-00 | RING, THREADED CYLINDER HEAD | 3 |
| 17 | TS-6316-0362-00 | CAP, THREADED CYLINDER HEAD | 3 |
| 18 | TS-6316-0092-00 | GASKET, VALVE COVER (G-741) | 3 |
| 19 | TS-7501-0051-00 | SCREW, RETAINER (UPPER) | 12 |
| 20 | TS-6397-0603-00 | PLATE, RETAINER (UPPER) | 3 |
| 21 | TS-6397-0575-00 | GUIDE, UPPER VALVE | 3 |
| 22 | TS-6316-0039-00 | COVER, VALVE POT | 3 |
| 23 | TS-6316-0373-00 | GASKET, WEAR PLATE (G-800) | 3 |
| 24 | TS-6316-0365-00 | PLATE, WEAR | 3 |
| 25 | TS-6316-0373-00 | GASKET, LINER (G-800) | 3 |
| 26 | TS-6316-0366-00 | RING, LINER THREADED | 3 |
| 27 | TS-6316-0367-00 | LINER LOCK | 3 |
| 28 | TS-7602-1600-25 | GASKET, DISCHARGE MANIFOLD | 3 |
| 29 | TS-7602-1600-61 | GASKET, SUCTION MANIFOLD | 3 |
